WARNING: Risk of Fire or Electric Shock

• To avoid damage, falling, electric shock or re, do not modify the xture or replace

accessories without conrming with the supplier rst.

• Only authorized, qualied personnel should install this xture and should follow the

owner’s manual. Any improper installation might cause failure, electric shock, re

or other injury, damage or hazard.

• Disconnect power before installation or any maintenance of the xture.

• To prevent re, these xtures are rated for use in 120V (62-1860 & 62-1861: 120-277V).

• The product is for interior use only, suitable for damp location.

• Protect the product against direct contact with water.

• For use in environments where an accumulation of non-conductive dust on the

xture may be expected.

• Clean with a soft or damp cloth, making sure the power is OFF.

• The product (without integrated sensor) is dimmable and compatible with most

residential dimmers.

• 5 Year limited warranty only in respect of any defect in material.

IMPORTANT: This product must be installed in accordance with the applicable

installation code by a licensed electrician familiar with the construction and operation

of the product and the hazards involved.

LED CLOUD FIXTURES

Models: 62-1850, 62-1851, 62-1852, 62-1853,

62-1858, 62-1859, 62-1860, 62-1861

Satco Products, Inc.

Brentwood, NY 11717

INSTALLATION AND SAFETY INSTRUCTIONS

IMPORTANT: Read before installing xture. Retain for future reference.

© Copyright 2024 Satco Products, Inc. 7/24 v1.0

11.5W: 62-1850, 62-1851 (w/Sensor)

14W: 62-1860 (120/277V 0-10V, Dimmable)

O/11" (279mm) x 3.13"D (79mm)

14W: 62-1852, 62-1853 (w/Sensor)

17W: 62-1861 (120/277V 0-10V, Dimmable)

O/14" (355.5mm) x 3.17"D (80mm)

25W: 62-1858, 62-1859 (w/Sensor)

O/19" (482.6mm) x 4.13"D (105mm)

INSTALLATION:

STEP 1: Turn OFF

power supply before

installation. Remove

the diffuser (shade).

STEP 2: Select

your preferred color

temperature (CCT) by

moving the switch to

either 2700K, 3000K,

3500K, 4000K or

5000K.

STEP 5: Replace the diffuser

(shade). Installation is complete.

Turn power ON.

STEP 3: Screw

the (2) screws to

3" or 4" junction

box using the

keyhole slots on

the pan of the

xture.

Wiring Diagram

Wiring Diagram

Only for 62-1860 & 62-1861

0-10V dimmable models.

STEP 4: Connect wires

separately (see wiring diagrams).

Cap all connections with wire

nuts (included). Push xture and

twist clockwise to lock the xture

with screws. Tighten the screws

with a screwdriver.
