1
WARNING: Risk of Fire or Electric Shock
• To reduce the risk of re, electrical shock or injury to persons; read and
follow all warnings and installation instructions before installing.
• All installation should be performed by a qualied electrician.
• To avoid electric shock, ensure power is turned off before installation or
inspection. All wiring must be installed in accordance with Electrical Code
and local electrical code.
• To prevent re, this xture is rated for use in 100-277V, 50-60Hz protected
circuit and minimum 75°C rated supply conductor.
• To prevent product malfunction and/or electrical shock, this product must
be properly grounded.
• To avoid damage and/or product malfunction, do not modify the xture
or replace accessories without conrming with the supplier rst.
• To prevent wiring damage or abrasion, do not expose wiring to edges of
sheet metal or other sharp objects.
• Suitable for indoor/outdoor applications.
IMPORTANT: This product must be installed in accordance with the
applicable installation code by a person familiar with the construction and
operation of the product and the hazards involved.
LED SMALL WALL PACK
Models: 65-747, 65-748, 65-749
Satco Products, Inc.
Brentwood, NY 11717
GENERAL INSTALLATION NOTES:
INSTALLATION AND SAFETY INSTRUCTIONS
IMPORTANT: Read before installing xture. Retain for future reference.
© Copyright 2022 Satco Products, Inc. 3/22 v1.1
1. Be sure all connections are protected.2. Be sure to set the desired color temperature inside
the xture before re-installing the bottom plate.
NOTE: To bypass photocell, unplug photocell from
the driver board.
Gray\Violet
STEP 1: Turn off power before installation,
then loosen the 4 screws on the xture and
remove the bottom plate.
STEP 2: Remove the 1/2 end cap.
INSTALLATION: A
12
Dimensions
147mmW x 218mmH x 78mmD
