Seite 1/7
EC REP
Prolinx GmbH Brehmstr. 56, 40239
Duesseldorf Germany
Prolinx Global LTD 27 Old Gloucester
Street London, WC1N 3AX, UK
UK REP
E-mail:
pixel@pixelhk.com
Add:
Building 2 No. 871, Dalang Section Guanzhang Road, Dalang
Town, Dongguan, China
Mfrs:
Dongguan Baoyi Electronic Technology Co., Ltd
Support: support@pixelhk.com User: retail@pixelhk.com
X10445 23.06 Made in China
USER MANUAL
User manual
使用说明书
1. Do not use the product in the environment with high temperature and high humidity.
2. It’s normal that the product may get hot while using it.
3. Do not leave the product in a place where there are corrosive chemicals, or it will be corroded
and damaged.
4. There are sophisticated electronic circuits in this product. So please contact authorized
personnel for maintenance. Any failures caused by unauthorized disassembly are not covered
by the warranty.
5. Please refer to the relevant national standard for use and operation. Any damage to the
machine caused by improper use is not covered by the warranty, but paid maintenance.
6. This user guidance is prepared based on the rigorous testing from this company. Further notice
will not be given if the design and specifications change.
WARNING PRODUCT VIEW
Wireless Receiver
User Manual*1
LIST OF ITEMS
Charging Case*1Wireless Receiver*1 Transmitter*2
Furry Windproof
Deadcat*2
USB-C Charging
Cable*1
3. LED Indicator
The pairing status is known by the LED indicators when
the receiver is connected.
4.USB-C Interface
It can charge cell phones and tablets with USB-C Connector.
2. Resetting Hole
Flashing
The indicator keeps on
Not paired/Pairing
Receiver Status
Paired
LED Indicator
3.5mm TRS Socket
Function Button
LED Indicator
Wireless Transmitter
Details are as below:
1. Lightning Connector
For connecting mobile phones and tablets with lightning
interface.
Microphone is out/into the charging casePower On / Off
Blue indicator flashes slowly
/Not paired Blue indicator flashes slowly
Double click the power switch in non-mute status;
double click again to go back to the acoustic mode
Paired, Acoustic mode
White indicator keeps on
Transmitter Status LED IndicatorOperation
Noise reduction mode Blue indicator keeps on
Click the function button onceMute On/Off Red indicator keeps on
Long press the function buttonPair up again Blue and red indicators flash alternately
/
/
Low battery Fast flashing in current mode (4 times/sec)
* When adjusting the noise reduction or acoustic mode of one transmitter, the other one will be synchronized with it, except for the
mute mode.
Lightning
Connector
Resetting
Hole
USB-C
interface
LED Indicator
PRODUCT VIEW
HOW TO USE
HOW TO USE
1. Wireless Transmitter Installation
a. Aim the top side of the transmitter at the sound
source. It can be clipped on the collar or other
places that close to the source.
b. For outdoor or windy environments, a furry
windproof deadcat is recommended.
b. Mobile devices and tablets can be charged when
plug the USB-C charging cable into the connector.
(charging only)
Back Clip
4. Paring
5. The Use of Charging Case
The receiver can be used without charging, while
the transmitter should be placed in the charging slot
for charging. The charging case can be charged by a
USB-C connector on the right side.
The transmitter and receiver are factory paired
by default and can pair up again as the following
steps:
2. External Microphone Not Included in (
this package)
Open the dust plug and plug the external
microphone directly into the 3.5mm socket.
3. Wireless Receiver Installation
a. Plug the receiver into a phone or tablet that
supports the connector.
a. Receiver: Press and hold the "Resetting Hole"
for about 0.5 second with a toothpick, needle, etc.
until the LED flashes, which indicates it’s reset
successfully.
b. Transmitter: Long press the Function Button for
about 2 seconds to pair up again.
c. The indicator of both receiver and transmitter
are always on, which indicates they are paired
successfully.
Note: The pairing process must be completed within
15 seconds, otherwise the above steps need to be
repeated.
Transmitters will automatically shut down after 10
minutes without pairing.
Charging Case
1. Charging Interface
For charging the charging case through USB-C interface.
2. Battery Indicator Button
Click the button, the battery of the charging case can be
shown by the LED indicator.
3. LED Indicator of the Charging Case
1
4
2
3
4. LED Indicator of the Charging Slot
Flashing Low battery
Keeps on(Light off when
fully charged)
On charge
Transmitter StatusLED Indicator Battery Status of Charging case LED Indicator
*When charging the charging case, the microphones inside are automatically charged, but the LED indicators of the
charging slot for microphones are off by default at this time.
Flashing
Keeps on
Low battery
Charging Case Battery Information
Regular battery
Flashing(when connected
to the charging cable)
On charge
Keeps on(when connected
to the charging cable)
Fully Charged
LED Indicator
