SF 116

v1.2

SF116 16-port switch for 16 IP cameras

Edition 4 from 29.01.2019 :

Supercedes the edition 3 from : 06.06.2018

Features:

 Switch 16 ports

16 10/100 PoE ports Mb/s (data transfer

and power supply)

2 ports G1/TP, G2/TP ports) (UpLink) 10/100/1000 Mb/s (

2 ports G1/SFP, G2/SFP ports) 10/100/1000Mb/s SFP (

(UpLink)

 W for each PoE port, supports devices complaint with 30

the IEEE802.3af/at standard (PoE+)

 Supports auto-learning and auto-aging of MAC addresses

(16K size)

 LED indication

 Additional assembly elements

 warranty 2 year from the production date –

Example of use.

1. Technical description.

1.1. General description.

SF is a -ports PoE switch designed to supply IP cameras operating in IEEE 802.3af/at standard 116 16 .

Automatic detection of any devices powered in the PoE/PoE+ standard is enabled at the 1 ports of the switch The G1/TP –8 .

and G2/TP ports is used for connection of another network device via RJ45 connector. The switch is fitted with SFP slots

(marked as G1/SFP and G2/SFP), the use of ber optic module (GBIC) allows ber optic transmission.The operating status of

the device (described in the table below) is displayed on the LED display on the front panel.

The PoE technology ensures a network connection and reduces installation costs by eliminating the need to supply a

separate power cable for each device. This method allows supplying other network devices, such as IP phone, wireless access

point or rou . ter

1.2. Block diagram.

Fig. 1. Block diagram.

1.3. Description of components and connectors.

Table 1 see Fig , 3 and 4) . ( . 2

Element no.

(Fig. 2)

Description

[1]

LED indication

[2]

16 x PoE port (1 ) ÷16

[3]

2 x UPLINK ports (G1/TP, P) G2/T

[4]

2 x UPLINK ports (G1/SFP, G2/SFP)

[5]

Power Socket of the 230 V

[6]

Additional mounting elements

Fig. 2. The front power of the switch.

Fig. 3. Rear panel of the switch.

Fig. 4. The view switch'a.

1.4. Technical parameters

Table 2.

Ports

16 x PoE (10/100Mb/s) (RJ-45)

2 UpLink (10/100/1000Mb/s) (RJ- x 45)

2 x UpLink (10/100/1000Mb/s) (SFP)

with connection speed auto-negotiation and MDI/MDIX Auto Cross)

PoE power supply

IEEE 802.3af/at ports), 52 V DC / 30 W at each port * (1÷16

Used pairs 1/2 (+), 3/6 (-)

Protocols, Standards

IEEE802.3, 802.3u, 802.3x CSMA/CD, TCP/IP

Bandwidth

14,8Gbps

Transmission method

Store-and-Forward

Optical indication of

operation

Switch power supply

Link

PoE Status

Power supply

~100-240 V; 50/60 Hz; 3 A

Operating conditions

temperature - 10°C ÷ 40°C,

relative humidity 5 - 90%, no condensation %

Dimensions

W=442, H=44, D=224 [+/- 2mm]

Additional equipment

bracket for Rack 19”

Cable length AC

1,2m

Net/gross weight

2,7 / 3,1kg

Protection class

EN 60950-1:2007

I (rst)

Storage temperatur

- 20°C ÷ 60°C

Declarations

* The given value of 30 W per port is the maximum value. The total power consumption should not exceed 160 W.

Produktspezifikationen

Marke:	Pulsar
Kategorie:	Nicht kategorisiert
Modell:	SF116
Breite:	442 mm
Tiefe:	224 mm
Gewicht:	2700 g
Produktfarbe:	Schwarz
Höhe:	44 mm
AC Eingangsspannung:	100 - 240 V
AC Eingangsfrequenz:	50 - 60 Hz
Betriebstemperatur:	-10 - 40 °C
Relative Luftfeuchtigkeit in Betrieb:	20 - 90 %
Paketgewicht:	3100 g
Netzstandard:	IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Power over Ethernet (PoE):	Ja
Ethernet LAN Datentransferraten:	10,100,1000 Mbit/s
LED-Anzeigen:	Link, Power, Status
Temperaturbereich bei Lagerung:	-20 - 60 °C
Switch-Typ:	Managed
Anzahl der basisschaltenden RJ-45 Ethernet Ports:	16
Basic Switching RJ-45 Ethernet Ports-Typ:	Fast Ethernet (10/100)
Auto MDI/MDI-X:	Ja
10G-Unterstützung:	Nein
MAC-Adressentabelle:	- Eintragungen
Routing-/Switching-Kapazität:	14.8 Gbit/s
Rack-Einbau:	Ja
Formfaktor:	1U
Anzahl Gigabit Ethernet (Kupfer) Anschlüsse:	2
Eingangsstrom:	3 A
Netzteil enthalten:	Nein
Menge SFP-Modul-Steckplätze:	2
Rackmontageset:	Ja
Power over Ethernet (PoE) Spannung:	52 V
Anzahl Power over Ethernet (PoE) Anschlüsse:	16
Power over Ethernet (PoE) Leistung pro Anschluss:	30 W
