* Before using this unit, carefully read “USING THE UNIT SAFELY” and “IMPORTANT NOTES”. After reading, keep the document where it will be available for

immediate reference.

English

Owner

’

s Manual

Points of caution during setup

¹Check the useable pipe size (diameter) to which the clamp can be attached,

as shown in “Main specications”. Tighten knob

1

according to the pipe

diameter when adjusting.

¹Only use your hands when tightening the knob, to avoid over-tightening and

damaging the parts.

¹When loosening knobs

1

and

2

, make sure to rmly hold the unit with one

hand, and carefully loosen the knobs without getting your ngers pinched.

¹After setup, make sure that the stand on which you mounted the

smartphone holder is stable.

¹Be careful not to let your smartphone fall. We do not provide compensation

for smartphones that may be damaged as a result of a fall.

Setup

Mount the smartphone holder onto your stand.

Knob

1

Knob

2

Nut

Body

Side arm

Head

Clamp

1. Loosen knob

1

and clamp the unit onto the stand.

2. Firmly tighten knob

1

, and lock the clamp onto the stand.

3. While rmly holding the body with one hand, use your

other hand to loosen knob

2

, adjusting the angle of the

body and the head.

4. Firmly tighten knob

2

.

5. Loosen the nut and adjust the orientation of the side arm.

6. Firmly tighten the nut.

7. Remove the disc of the side arm from the disc of the head.

8. Widen the side arm so that your smartphone tightly

ts between the arms.

9. Attach the disc of the side arm on which you mounted your

smartphone to the disc of the head.

* Make sure that the disc of the side arm ts within the disc of the head, so that

the unit rmly holds your smartphone.

10.

Last, make sure that knobs

1

and

2

as well as the nut are all

tightened.

MEMO

Since the side arm is magnetically attached to the head, it can be removed or swiveled. You

can use your smartphone in either portrait or landscape orientation, as you like.

Main specications

Compatible smartphone

size

Width: 64–80 mm (2-9/16–3-3/16 inches)

Thickness: 10 mm or less (7/16 inched or less)

Weight: 250 g or less (9 oz or less)

Compatible pipe diameter

Vertical pipe diameter: 19–38 mm

Horizontal pipe diameter: 22–38 mm

Weight

370 g (14 oz)

* This document explains the specications of the product at the time that the

document was issued. For the latest information, refer to the Roland website.

USING THE UNIT SAFELY

IMPORTANT NOTES

Used for instructions intended to alert the

user to the risk of injury or material

damage should the unit be used

improperly.

* Material damage refers to damage or

other adverse eects caused with

respect to the home and all its

furnishings, as well to domestic animals

or pets.

Used for instructions intended to alert the

user to the risk of death or severe injury

should the unit be used improperly.

The symbol alerts the user to things that must be

carried out. The specic thing that must be done is

indicated by the design contained within the circle. In the

case of the symbol at left, it means that the power-cord

plug must be unplugged from the outlet.

The symbol alerts the user to important instructions or

warnings. The specic meaning of the symbol is

determined by the design contained within the triangle. In

the case of the symbol at left, it is used for general

cautions, warnings, or alerts to danger.

The symbol alerts the user to items that must never be

carried out (are forbidden). The specic thing that must

not be done is indicated by the design contained within

the circle. In the case of the symbol at left, it means that

the unit must never be disassembled.

About WARNING and CAUTION Notices

About the Symbols

ALWAYS OBSERVE THE FOLLOWING

INSTRUCTIONS FOR THE PREVENTION OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS

WARNING

CAUTION

WARNING

Do not disassemble or modify by

yourself

Do not carry out anything

unless you are instructed

to do so in the owner’s

manual. Otherwise, you

risk causing malfunction.

Do not repair or replace parts by

yourself

Be sure to contact your

dealer, a Roland service

center, or an ocial

Roland dealer.

For a list of Roland service centers

and ocial Roland dealers, refer to

the Roland website.

Do not place in an unstable location

Otherwise, you risk

injury as the result of

the unit toppling over or

dropping down.

Be cautious to protect children from

injury

Always make sure that

an adult is on hand to

provide supervision and

guidance when using

the unit in places where children

are present, or when a child will be

using the unit.

WARNING

Do not drop or subject to strong impact

Otherwise, you risk

causing damage or

malfunction.

CAUTION

Evaluate safety issues before using this

unit

Even if the precautions described in

the Owner’s Manual are followed,

this unit or your smartphone may

fall o, depending on how they

are handled. Please be mindful of

any safety issues before using this

product.

Take care so as not to get ngers

pinched

When adjusting this

unit, be careful not to

get your ngers or other

extremities pinched.

Whenever a child uses the unit, an

adult should be on hand to provide

supervision and guidance.

¹Movable/rotating parts

¹Side arm

¹Head and side arm attachment

¹Clamp

Maintenance

¹Never use benzine, thinners,

alcohol or solvents of any

kind, to avoid the possibility

of discoloration and/or

deformation.

Additional Precautions

¹When disposing of the packing

carton or cushioning material in

which this unit was packed, you

must observe the waste disposal

regulations that apply to your

locality.

Intellectual Property Right

¹Roland is either registered

trademarks or trademarks of

Roland Corporation in the United

States and/or other countries.

¹Company names and product

names appearing in this

document are registered

trademarks or trademarks of

their respective owners.

© 2025 Roland Corporation
