POCKET RGB VIDEO LIGHT

USAGE INSTRUCTIONS

®

®

REMOVE SHOE

MOUNT FROM

BALL HEAD

CHARGE PORT

ON/OFF SWITCH

ON/OFF SWITCH

BRIGHTNESS

HUE/SATURATION/BRIGHTNESS

TOGGLE CCT/RGB

TOGGLE CCT/RGB

KELVIN TEMP

MOUNT TO A CAMERA

To attach to a camera with a shoe mount, screw the included ball head into the bottom of the Pocket

RGB Video Light. Slide the shoe mount adapter on the bottom of the ball head into the camera shoe

mount. Tighten using the knurled knob to secure.

MOUNT TO A LIGHT STAND

To mount to a light stand, unscrew the shoe adapter from the bottom of the ball head and thread the ball

head into any light stand with a ¼”-20 male thread.

CHARGING

Plug the USB end of the supplied power cord into the AC wall adapter. Plug the USB-C end of the cord

into the port on the side of the light. Charging will begin automatically. Charging from a fully drained light

to full power can take up to 2 ½ hours.

BACK PANEL CONTROL

Slide the On/Off bar to the On position. The back panel will display in the mode it was last used.

To change from CCT (color correcting) mode to RGB (color) mode, press the CCT/Hue button in and

hold for 2 seconds. The light will shift to the RGB bulbs. To go back to CCT mode, repeat.

CCT MODE

In CCT mode, the back panel will display:

TOP LEFT: current Kelvin temperature

BOTTOM LEFT:brightness level

TOP RIGHT: expected run time at the current brightness level

To increase brightness, press the upward arrow button until the desired level is reached. Press the

downward arrow to decrease. To increase Kelvin temperature, press the right arrow. Press the left arrow

to decrease the Kelvin temperature. 5600K is considered daylight and 3200K is a tungsten source

similar in appearance to an incandescent household bulb. Adjusting the Kelvin temperature can be used

to achieve color accuracy (5600K) or gradually warm the subject by decreasing. Besides warming the

subject for creative purposes, the feature can also be used to match the available light already present

in any environment. Almost all locations will be somewhere between 3200K and 5600K.

RGB MODE

After switching to RGB mode, the panel will display:

TOP LEFT: “Hue” (color)

MIDDLE LEFT: “Sat.” (saturation)

BOTTOM LEFT:“Int.” (brightness)

“Hue” allows selection of 360 available colors while “Sat.” allows adjustment of the intensity of each

selected color. To select a desired color, press the right or left arrows to scroll through the 360

available colors.

0 = RED, 120 = GREEN, 240 = BLUE

To change the saturation of a selected color, press the CCT/Hue button one time. You can now use the

right/left arrow to increase or decrease the saturation of the color. At any selected color or saturation,

press the up arrow to increase light output and the down arrow to decrease.

SAVAGE UNIVERSAL CORPORATIONSAVAGEUNIVERSAL.COM 800.624.8891
