Seite 1/4
System Type
Direct drive for sound masking
Sensitivity dB @ 2.83V/1M
69 dB
10
Sensitivity dB @ 1W/1M
2
69 dB
10
Frequency Response (- 3 dB)
3
90 Hz - 10 kHz
Frequency Response (-10 dB)
3
80 Hz - 15 kHz
Max. Program Power
4
50 w
Max. Continuous Power RMS
5
30 w
Max. Power SPL @ 1 M
6
86 dB (drywall)
Coverage Angle (-6 dB @ 2 kHz)
120º
Coverage Angle (-6 dB @ 10 kHz)
120º
Enclosure Material
Titanium adonized aluminum
Grille
N/A
Inputs
Plenum rated wire lead with screw connector block
Colors
Titanium
Height
120.65 mm | 4.75 in
Diameter
58.42 mm | 2.30 in
Weight
0.68 kg | 1.5 lbs
Accessories
Conduit Clamp
Optional
Titanium Heat Sink (SD1-HS-TI)|12” On-Center Bracket Assembly
(SD1-BR12)|16” On-Center Rear-Install Drywall Bracket assembly
for SolidDrive (SD1-BR16-R)|16” On-Center Bracket Assembly
(SD1-BR16)|24” On-Center Bracket Assembly (SD1-BR24)|Passive
Equalization Module - Drywall (PEM-DW)
Packaging
1 per box
Regulatory - CE
Approved
Regulatory - UL
UL 1480A & 2043 approved
RoHS
Approved
Notes:
2 1w1m sensitivity determined using nominal impedence
3 Frequency response measured in half or full space as dictated by speaker mounting conguration
4 Max program power is 3 dB above max continuous power
5 Continuous power rating EIA-426-B test
6 Max output based on max continuous power
10 Equivalent to conventional in-wall @ 4m
Description
The MSK-1-T by SolidDrive is an economical hidden
planar-source sound transducer designed for sound
masking on drywall, glass and wood. Featuring a rugged
aluminum enclosure with neodymium magnets, the
MSK-1 uses technology similar to our patented SD1
transducers to transfer acoustic energy to the substrate.
The result is extremely wide and even audio coverage and
acoustical uniformity in the listening space.
Key Features
• Hidden planar-source audio technology evenly
distributes sound masking signals throughout the
listening space.
• Broad and even coverage of up to 15 feet per unit in a
drywall installation means a few units cover a large area.
• Proprietary behind-surface mounting technologies
ensure maximum visual appeal.
• 86 Max SPL (drywall) and 120° dispersion pattern
across the upper registers of the frequency spectrum.
• Drywall optional accessories: self-leveling, constant
tension pre-construction bracket to ensure proper
alignment & wall contact.
• incorporates a 10 watt transformer for use in
70 V installations
• SolidDrives operate in a virtually friction-free
environment and are engineered for innite life.
SolidDrives come with an industry-leading 7-year
warranty.
MSK-1-T PRODUCT SPECIFICATIONS
SolidDrive MSK-1-T Series
MSK-1-T | MSK-1sm-T | MSK-1g-T
Commercial Applications
MSK-1 by SolidDrive technology allows for high
quality sound through drywall surfaces in either in-wall
or in-ceiling installations. Applications include any sound
masking installation in ceilings or walls that requires a
hidden speaker solution. With planar-source technology,
the location of the SolidDrive on the surface has no impact
on the quality or uniformity of the delivered sound eld
and each unit provides coverage over a large area. For
improved bass response, SolidDrive IW200 (dual 8 inch)
or IW210 (dual 10 inch) subwoofers can be included.
SoundTube
®
13720 W. 109th St.
Lenexa, KS 66215
Phone: 913.663.5600
Fax: 913.663.3200
Toll Free: 855.663.5600
www.soundtube.com
All SoundTube speakers come with a 7-year
limited warranty.
