Seite 1/14
FR /Guide d’intégration
EN /Integration guide
DE - IT - ES - PT- HU
02
EN
IMPORTANT
BEFORE STARTING, READ THESE RECOMMENDATIONS:
This generic manual is provided to help you assemble your computer. The actual installation varies
with the specifications of the case that you purchased.
For more advanced instructions, please refer to the installation manuals for your motherboard,
graphic card, etc., and all the different peripherals that you wish to install while assembling your
configuration! We decline all liability for any incorrect component handling and/or installation.
Stability and cleanliness: To assemble the case, make sure you have a flat and stable work surface.
Assemble the case away from dust in a well-lit room! Never lay the case on a carpet charged with
static electricity.
Take your time: Carefully handle the case to avoid any risk of injury. Despite the care that we take
when manufacturing our products, some may still have sharp inside edges! Avoid any sudden
movement. We recommend wearing gloves.
Always read the instructions first… Every component is different! Start by reading the assembly
instructions for each of your computer’s component parts like the CPU, RAM, etc. For example: refer to
the instructions that come with your CPU cooler to identify the steps that you need to take into
account before installing the motherboard.
What does anti-static mean ? To preserve component integrity, it is essential to protect them from
any static electricity discharge that may be caused by your body becoming charged. Wear an
anti-static wrist band so that you can handle parts safely. Handle components and cards with care
and never touch unshielded components or contacts. Always hold your card, your processor by its
edges (never its pins).
Use the right tools ! We recommend that you always use the right tools for every assembly step.
Never use a “makeshift” screwdriver like a coin, a knife tip, your fingernails, etc. You may damage
your equipment or injure yourself. During assembly never overtighten components or you may
damage the threads or break the equipment.
Never force things ! Before connecting a cable, make sure that both connectors are correctly aligned.
Connectors are often fool-proofed: this means that they are fitted with a mechanism, generally a
mechanical one, that inhibits any assembly or connection errors! Never force things as bent
connector pins may require replacing the entire connector!
Any questions ? If you have any doubts or if you cannot assemble your components, contact the
support department or seek the help of a qualified technician.
03
EN
REMOVING THE CASE SIDE
INSTALLING THE MOTHERBOARD
INSTALLING 2.5" / 3.5" HARD DISK AND OPTICAL DISC DRIVES
Before installing a hard disk drive check the amount of space required and the length of your graphic
card. Depending on the case, connecting disks may be complicated or require removing cradles or
racks. The graphic card may also require attaching a mounting rail or moving a removable fan rail.
- There are a variety of hard disk drive mounting systems. Some of our cases do not require screws:
- Quick-fit cradle mounting: Insert the disk into the cradle, then lower the lever to hold it in place.
- Removable clip-fit cradle: Remove the cradle by pressing the tabs / Insert the disk drive into the holes
on one side / Spread the cradle to insert the other side of the disk drive / Refit the cradle into the rack.
- For screw mounted cages/cradles/rail, always use the screws supplied and do not forget to use
vibration damping washers where necessary.
Start by unpacking it and placing it on the protective foam that it came with. This way you have a more
comfortable working area to install the CPU, its cooling system that generally comprises a heat sink
with a fan on top, and the memory, etc. Follow the assembly instructions for every component!
Before positioning the motherboard, attach the back connector panel sold with the motherboard by
clipping it to the side of the case. Depending on the format of the motherboard used, check the
spacers already installed on the case or add new ones. Position the motherboard and screw it into
the case. Remember, never overtighten! Take care to never fix more spacers than there are holes in
your motherboard or you may create short circuits.
To remove the case side, unscrew the knurled screws. Depending on the model, use a suitable
screwdriver.
