Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: May 12, 2023 2:48 PM

Product ID

4U2525-SAS-BACKPLANE

Front

Front

Rear

4-Bay 2.5in U.2 (SFF-8639) Drive Backplane

ComponentFunction

1Frame Mounting Holes

• Secure the to the 4-Bay Drive Backplane

Computer Case

• 4 Holes on each side of the Backplane

2Drive Bay/Drive Tray

• Hosts a and is removable from U.2 NVMe Drive

the 4-Bay Drive Backplane

3

Drive Bay Release Latch

• Used to remove the from the Drive Tray

Backplane

4Drive Bay Key Hole

• Use the included to or Set of KeysLock Unlock

the Drive Tray

5LED Indicator

• Solid Blue: DriveIndicates the is receiving power

• Blinking Blue: DriveIndicates activity

• Blinking Red: Drive Cooling FanIndicates a

failure

6Fan Speed Switch

• Change the speed between Drive Cooling Fans

High Lowor

7Drive Cooling Fans

• Provides airow to assist in cooling the U.2

NVMe Drives

8

Mini-SAS Connectors

(SFF-8643)

• Connect to a in the U.2 NVMe ControllerHost

Computer

9SATA Power Connector

• Connect available from the SATA Power

Computer’s Power Supply to provide power to

the U.2 NVMe Drives

Product Information

For the latest drivers/software, technical specications, and declarations of

conformance, please visit: www.StarTech.com/4U2525-SAS-BACKPLANE

Requirements

• Desktop with:

• Available 5.25” Expansion Bay x 1

• SAS (SFF-8643) Host Connector Ports x 4

• SATA Power from Computer Power Supply x 1

• 2.5” U.2 (SFF-8639) NVMe Drives x 4

1

1

2

543

6

88

7

7

9
