Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: September 9, 2019 10:18 AM

Product Diagram (BRACKET125PTP)

ComponentFunction

1Hard Drive Slot

• Used to secure a or 2.5” Solid State Drive

Hard DriveMounting Bracket in the .

2Plastic Pegs

• Used to secure the to the Mounting Bracket

Computer Chassis.

3Handle

• Used to insert/remove the Mounting Bracket

into/out of the .Computer Chassis

Requirements

For the latest requirements, please visit www.startech.com/BRACKET125PTP

Packaging Contents

• 2.5” SSD/HDD Mounting Brackets x 5

• Plactic Pegs x 30

• Quick-Start Guide x 1

2.5” SSD/HDD Mounting Bracket for 3.5” Bay | Tool-less | 5 Pack

Installing a Hard Drive

1. Remove the (x 6) from the center of the by gently Plastic PegsMounting Bracket

twisting the until it snaps o of the plastic molding.Plastic Peg

2. Slide the into the on the towards Hard DriveHard Drive SlotMounting Bracket

the , label side down, with the facing out.HandleHard Drive Connector

Inserting a Hard Drive into the Mounting Bracket

Installing the Mounting Bracket

1. Turn o the and any connected (e.g., printers, ComputerPeripheral Devices

external hard drives, etc.).

2. Unplug the from the back of the and disconnect any Power CableComputer

Peripheral Devices.

3. Remove the from the .CoverComputer Case

Note: Please refer to the manufacturer’s manual for instruction on how to remove the

Computer Case Cover.

4. Slide the (label side up) into a , aligning Mounting Bracket3.5” Hard Drive Slot

the on the with the on the Mounting HolesMounting BracketMounting Holes

Computer Chassis.

Sliding the Mounting Bracket into the 3.5” Hard Drive Slot

2

3

1
