Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: September 8, 2021

Product Diagram (DS52000)

Front Angle View

Rear Angle View

Side Angle View

Bottom Angle View

5 Port 2.5G Unmanaged Multi-Gigabit Ethernet Switch

Port Function

1Power LED indicating is on• Green LED Power

2Link Speed LEDs

• Green LED Link Speed Ethernet Indicating for the

Port

• Row Link SpeedTop - 10/100/1000Mbps

• Row Link SpeedBottom - 2.5Gbps

3Ethernet Ports

• Connect the to Ethernet Enabled Network Device

the Ethernet Switch

4DC Power Input

• Connect the to the Universal Power Adapter

Ethernet Switch

5K-Slot • Connect a to the K-Slot Lock Ethernet Switch

6Wall Mount Connectors • Connect the to the Wall Mounts Ethernet Switch

Product Information

For the latest product information, technical specications, manuals, and Declarations

of Conformance please visit: www.StarTech.com/DS52000

Package Contents

• Ethernet Switch x 1

• Universal Power Adapter x 1

• Wall Mounting Kit x 1

• Quick-Start Guide x 1

Hardware Installation

Mounting the Ethernet Switch (optional)

1. Attach the to the by matching the on the Wall Mounts Ethernet Switch Keying

Wall Mounts Keying Wall Mount Connectors Wall to the of the and slide the

Mounts Ethernet Switch Wall Mounts towards the center of the to lock the in

place.

2. Mount the by screwing it to the using Ethernet Switch Mounting Location

Appropriate Screws Mounting Surface Material (not included) for the .

Connecting the Ethernet Switch

1. Connect the to a using the Ethernet Switch Power Outlet Universal Power

Adapter

2. Connect up to 5 to the using Ethernet Enabled Network Devices Ethernet Switch

Ethernet Cables (Cat5e or better).

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could void

the user’s authority to operate the equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:

(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may

cause undesired operation of the device.

Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation

est autorisée aux deux conditions suivantes:

(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,

même si le brouillage est susceptible d’en compromettre le fonctionnement.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-

party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which

this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the

property of their respective holders.

Warranty Information

This product is backed by a two-year warranty.

For further information on product warranty terms and conditions, please refer to .www.startech.com/warranty

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents)

for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss of

business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations

or exclusions contained in this statement may not apply to you.

Safety Measures

• If product has an exposed circuit board, do not touch the product under power.

Mesures de sécurité

• Si l’un des circuits imprimés du produit est visible, ne pas touchez le produit lorsqu’il est sous tension.

安全対策

• 製品に露出した状態の回路基盤が含まれる場合、電源が入っている状態で製品に触らないでください。

Misure di sicurezza

• Se il prodotto ha un circuito stampato visibile, non toccare il prodotto quando è acceso.

Säkerhetsåtgärder

• Rör aldrig vid enheter med oskyddade kretskort när strömmen är påslagen.

FR: startech.com/fr

DE: startech.com/de

ES: startech.com/es

NL: startech.com/nl

IT: startech.com/it

JP: startech.com/jp

StarTech.com Ltd.

45 Artisans Crescent

London, Ontario

N5V 5E9

Canada

StarTech.com Ltd.

Unit B, Pinnacle 15

Gowerton Road

Brackmills,

Northampton

NN4 7BW

United Kingdom

StarTech.com LLP

4490 South Hamilton

Road

Groveport, Ohio

43125

U.S.A.

StarTech.com Ltd.

Siriusdreef 17-27

2132 WT Hoofddorp

The Netherlands

Produktspezifikationen

Marke:	StarTech.com
Kategorie:	Nicht kategorisiert
Modell:	DS52000
Breite:	120 mm
Tiefe:	145 mm
Gewicht:	600 g
AC-Netzadapter:	Ja
Produktfarbe:	Schwarz
Höhe:	30 mm
Energiequelle:	AC/DC
AC Eingangsspannung:	100 - 240 V
Betriebstemperatur:	0 - 45 °C
Relative Luftfeuchtigkeit in Betrieb:	10 - 90 %
Verpackungsbreite:	285 mm
Verpackungstiefe:	135 mm
Verpackungshöhe:	70 mm
Paketgewicht:	700 g
Netzstandard:	IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x
Quality of Service (QoS) Support:	Ja
Schnellstartübersicht:	Ja
Vollduplex:	Ja
Power over Ethernet (PoE):	Nein
Warentarifnummer (HS):	85176990
Gehäusematerial:	Stahl
LED-Anzeigen:	Ja
Temperaturbereich bei Lagerung:	-20 - 60 °C
Switch-Typ:	Unmanaged
Anzahl der basisschaltenden RJ-45 Ethernet Ports:	5
Basic Switching RJ-45 Ethernet Ports-Typ:	2.5G Ethernet (100/1000/2500)
Netzstecker:	DC-Anschluss
Auto MDI/MDI-X:	Ja
10G-Unterstützung:	Nein
Kupfer Ethernet Verkabelungstechnologie:	10BASE-T, 1000BASE-TX, 2500BASE-T
MAC-Adressentabelle:	- Eintragungen
Routing-/Switching-Kapazität:	2.5 Gbit/s
Jumbo Frames Unterstützung:	Ja
Rack-Einbau:	Nein
Stromstecker-Typ:	Typ M
Anzahl Produkte pro Versandkarton:	10 Stück(e)
Länge des Versandkartons:	370 mm
Breite des Versandkartons:	305 mm
Höhe des Versandkartons:	290 mm
Wandmontageset:	Ja
Ausgangsstrom:	1 A
Ausgangsspannung:	12 V
Nachhaltigkeitszertifikate:	CE, RoHS
Eingangsstrom:	0.5 A
Wandmontage:	Ja
Store-and-Forward:	Ja
unterstütze Kabeltypen:	Cat5e, Cat6, Cat6a
Netzteil enthalten:	Ja
Jumbo-Frames:	9000
Maximum Kabellänge:	100 m
Anzahl 2.5G Ethernet (Kupfer)-Ports:	5
