Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: June 5, 2019 4:02 PM

Product Diagram (HB30A10AME)

ComponentFunction

12-Wire Terminal Block

• Used to connect an external DC Power Source

(7~24V DC Input) to the .Hub

2Screw Locks (x 10)

• Used to securely lock a to the USB Device

USB-A PortHub on the .

• Center to center 19 Screw Lock Dimensions:

mm, thread size 4 - 40.

3Power LED

• : Indicates that the Hub is receiving Green

power.

4USB-B Host Port

• Used to connect a to the .Host ComputerHub

• Center to center 24 Screw Lock Dimensions:

mm, thread size 4 - 40.

5USB-A Ports (x 10)

• Used to connect ( x 10) to the USB Devices

Hub.

• Used to charge connected .USB-A Devices

• USB-A Ports support surge and 15KV ESD

(Electrostatic Discharge) Protection.

10-Port Industrial USB 3.0 (5 Gbps) Hub | USB 3.1 Gen 1 to 10x USB-A | ESD & Surge Protection

3

Requirements

For the latest requirements, please visit . www.startech.com/HB30A10AME

• Phillips Head Screwdriver

• Writing Utensil

• Level

• Mounting Screws (x 2)

Installation

Notes: It is recommended to use an external (+7 - 24V DC)DC Power Source

connected to the to ensure sucient power/current is 2-Wire Terminal Block

delivered to each on the . USB-A PortHub

The can also be powered by a HubHost ComputerUSB-B Host connected to the

Port, when using low power consuming USB Devices.

Powering the Hub Using the Universal Power Adapter

1. Connect the to the and to a Universal Power AdapterTerminal Block AC

Electrical Outlet.

2. Connect a (the end will depend on USB Port you are USB-B to USB Cable

connecting to) to the and to a USB port on the .USB-B Host Port Host Computer

3. The should detect the and automatically Host Computer’s Operating SystemHub

install it.

4. Connect your to the (x 10) on the .USB DevicesUSB-A PortsHub

Powering the Hub Using USB

1. Connect a (the end will depend on USB Port you are USB-B to USB Cable

connecting to) to the and to a USB port on the .USB-B Host Port Host Computer

2. The should detect the and automatically Host Computer’s Operating SystemHub

install it.

3. Connect your to the (x 10) on the .USB DevicesUSB-A PortsHub

Powering the Hub Using the 2-Wire Terminal Block

1. Remove the from the .Terminal Block Connector HousingHub’s Casing

2. Using a small screwdriver (Phillips or Flat Head), loosen the screws on the Terminal

Block Connectors.

4

5

2

1
