Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: May 16, 2023 4:31 PM

Product ID

M2-REMOVABLE-PCIE-N1

ComponentFunction

1Full-Prole Bracket

• Secure the to the M.2 to PCIe AdapterComputer

Case

2Bracket Mounting Screws

• Secure the to the Full/Low Prole BracketM.2 to

PCIe Adapter

3M.2 Drive TrayHosts the for the • M.2 DriveM.2 to PCIe Adapter

4PCIe p1-x4 Connector

• Connect the to a PCIe to M.2 to PCIe Adapter

PCIe SlotComputer in the

M.2 NVMe SSD Bay for PCIe p1-x4 Expansion Slot

5Key Lock for Drive Tray

• Use the included to Lock or Unlock the KeyM.2

Drive TrayM.2 to PCIe Adapter from the

6Drive LED Indicator

• Red: Connected Drive is Not Supported

• Green: Connected Drive is Supported

• Yellow: Flashes to indicate Drive Activity

Requirements

For the latest drivers/software, technical specications, and declarations of

conformance, please visit: www.StarTech.com/M2-REMOVABLE-PCIE-N1

Package Contents

• M.2 to PCIe Adapter x 1

• Low-Prole Bracket x 1

• M.2 Drive Tray x 1

• Quick-Start Guide x 1

Installation

Warning: PCIe Cards can be damaged by static electricity. Ensure that the Installer

is properly grounded before they open the Computer Case or touch the M.2 to PCIe

Adapter. The Installer should wear an Anti-Static Strap when installing any computer

component. If an Anti-Static Strap is not available, discharge any built-up static

electricity by touching a large Grounded Metal Surface for several seconds. Only

handle the M.2 to PCIe Adapter by its edges and do not touch the gold connectors.

(Optional) Installing the Low Prole Bracket

Note: By default the is attached to the Full Prole BracketM.2 to PCIe Adapter.

Depending on the system conguration the may need to be Full Prole Bracket

removed and replaced with the (included).Low Prole Bracket

1. Using a , remove the two securing Small Phillips Head ScrewdriverBracket Screws

the to the. Set the aside Full Prole Bracket M.2 to PCIe AdapterBracket Screws

as they will be used to attach the .Low Prole Bracket

2. Align the on the with the on the Screw Holes M.2 to PCIe AdapterScrew Holes

Low Prole Bracket ensuring the M.2 to PCIe Adapter is sitting on-top of the

Screw HolesLow Prole Bracket on the .

3. Insert the through the and into the Bracket ScrewsM.2 to PCIe Adapter Screw

HolesLow Prole Bracket on the .

4. Using the , tighten the , being Small Phillips Head ScrewdriverBracket Screws

careful not to over-tighten them.

1

2

4

5

3

6
