Instruction Manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 01/31/2012

For the most up-to-date information, please visit: www.startech.com

Packaging Contents

• 1xRiserCard

• 1xInstructionManual

System Requirements

• PCIExpressenabledcomputersystemwithavailablex4/x8PCIe

slot

• 1Userverchassis

Installation

WARNING!PCIExpresscards,likeallcomputerequipment,canbeseverelydamagedbystaticelectricity.Besurethatyouareproperly

groundedbeforeopeningyourcomputercaseortouchingyourPCIExpresscard.StarTech.comrecommendsthatyouwearananti-static

strapwheninstallinganycomputercomponent.Ifananti-staticstrapisunavailable,dischargeyourselfofanystaticelectricitybuild-upby

touchingalargegroundedmetalsurface(suchasthecomputercase)forseveralseconds.AlsobecarefultohandlethePCIExpresscardby

itsedgesandnotthegoldconnectors.

1. Makesurethatyoursystemisunpoweredandunpluggedandyouaregrounded.

2. Removethecoverofyoursystem(refertocomputersystemdocumentation,ifnecessary)sothatthePCIExpressexpansionslotopenings

onthemotherboardareaccessible.

3. AlignthePCIExpressconnectorontherisercardwithanavailablePCIExpressslot.

4. Gentlyinsertthecardintotheemptyslot,makingsureitisseatedrmly.Fastenthecardtotherisercardmountingbracketonthe

computerchassis(refertocomputersystemdocumentation,ifnecessary).

5. InstallthedesiredPCIExpresscardintothePCIeslotontherisercardandfastensecurelytothecomputerchassis(refertocomputer

systemdocumentation,ifnecessary).

6. Replaceandfastenthecomputercover.

PEX4RISER / PEX8RISER

PCI Express Riser Card - p1-x4 Left Slot Adapter for 1U Servers

*actual product may vary from photos

PEX8RISER

PEX4RISER

FCC Compliance Statement

ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainst

harmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,maycause

harmfulinterferencetoradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioor

televisionreception,whichcanbedeterminedbyturningtheequipmentoandon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowingmeasures:

• Reorientorrelocatethereceivingantenna.

• Increasetheseparationbetweentheequipmentandreceiver.

• Connecttheequipmentintoanoutletonacircuitdierentfromthattowhichthereceiverisconnected.

• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to

StarTech.com.WheretheyoccurthesereferencesareforillustrativepurposesonlyanddonotrepresentanendorsementofaproductorservicebyStarTech.com,oranendorsementoftheproduct(s)

towhichthismanualappliesbythethird-partycompanyinquestion.Regardlessofanydirectacknowledgementelsewhereinthebodyofthisdocument,StarTech.comherebyacknowledgesthatall

trademarks,registeredtrademarks,servicemarks,andotherprotectednamesand/orsymbolscontainedinthismanualandrelateddocumentsarethepropertyoftheirrespectiveholders.

Technical Support

StarTech.com’slifetimetechnicalsupportisanintegralpartofourcommitmenttoprovideindustry-leadingsolutions.Ifyoueverneedhelpwithyourproduct,visitwww.startech.com/supportandaccess

ourcomprehensiveselectionofonlinetools,documentation,anddownloads.

Forthelatestdrivers/software,pleasevisitwww.startech.com/downloads

Warranty Information

Thisproductisbackedbyatwoyearwarranty.

Inaddition,StarTech.comwarrantsitsproductsagainstdefectsinmaterialsandworkmanshipfortheperiodsnoted,followingtheinitialdateofpurchase.Duringthisperiod,theproductsmaybereturned

forrepair,orreplacementwithequivalentproductsatourdiscretion.Thewarrantycoverspartsandlaborcostsonly.StarTech.comdoesnotwarrantitsproductsfromdefectsordamagesarisingfrom

misuse,abuse,alteration,ornormalwearandtear.

Limitation of Liability

InnoeventshalltheliabilityofStarTech.comLtd.andStarTech.comUSALLP(ortheirocers,directors,employeesoragents)foranydamages(whetherdirectorindirect,special,punitive,incidental,

consequential,orotherwise),lossofprots,lossofbusiness,oranypecuniaryloss,arisingoutoforrelatedtotheuseoftheproductexceedtheactualpricepaidfortheproduct.Somestatesdonotallow

theexclusionorlimitationofincidentalorconsequentialdamages.Ifsuchlawsapply,thelimitationsorexclusionscontainedinthisstatementmaynotapplytoyou.

Specications

PEX4RISER PEX8RISER

Bus Interface PCIExpress

(x4slotconnector)

PCIExpress

(x8slotconnector)

Connectors x4PCIExpressslot x8PCIExpressslot

Operating Temperature 0°C~60°C(32°F~140°F)

Storage Temperature 0°C~60°C(32°F~140°F)

Humidity 5%~95%RH

Dimensions (LxWxH) 158.0mmx32.0mmx15.0mm

Weight 20g
