ALLURE™ ALUMINIUM LOUVRE-PATIO INSTALLATION GUIDE

ALLURE

™

INSTALLATION GUIDE

INSTALL GUIDE

• Drill and Hex-Head Adaptor

• Rivet Gun

• Tape Measure

• Tin Snips

• Spirit Level

• Post Hole Digger

• Silicone Gun

• Spanners or Ratchet

• Adjustable Construction Props

• Concrete

• Ladder

• Vise Grips

• Countersinking Drill Bit

• Phillips-Head Screwdriver

• Hole-Saws (ø13mm & ø16mm)

TOOLS REQUIRED

BEFORE YOU START

Carefully read these instructions and refer to them constantly during each stage of construction. If you do not have all the necessary tools or information,

contact Stratco for advice. Before starting, layout all components and check them against the delivery docket. The parts description identifies each key part,

and the component layout diagram indicates their fastening position.

Double check all dimensions, levels and bolting locations before cutting, screwing or bolting structural members. It is recommended that the installers erecting

the structure have had some previous building experience because some modifications to the existing house structure may be required. If a freestanding unit

is being installed, the attachment beam becomes the rear fascia beam and is installed as per the details for the front fascia beam. Box gutters and flashings do

not need to be pre-fixed until all beams have been erected.

Note: All screws within the unit must be fastened by hand using a screw-driver, or a low-torque, low-speed drill.

Using a powered tool may result in screw heads shearing from the shank. If screw heads shear from shank it is recommended

that a Screw Extractor kit is used to remove the screw.

Note: Allure components are designed for 1° fall to accommodate the minimum required louvre fall and Allure

construction should allow for this. A minimum 1:200 fall shall be maintained during construction for gutter fall toward

downpipes when this is perpendicular to louvre direction.
