Seite 1/3
Omada Reverse PoE Switch
|
Datasheet
RP108GE
Omada 8-Port Gigabit Reverse PoE Switch
• 7 PoE input and 1 PoE output 10/100/1000 Mbps RJ45 Ports
• 1 DC output port that supports both 5V and 12 V voltage switching
• Durable metal casing of superior quality and professional appearance
• Intelligent management via a web user interface and downloadable utility
• Green technology reduces power consumption
Highlights
Product Pictures
Specications
Hardware Features & Performance
Model RP108GE V1.20
General
Interfaces
7 Passive PoE-in RJ45 Ports:
10/100/1000Mbps Auto-Negotiation
Voltage: 24/48 V (mixture is not supported)
Power pin of Ethernet cable: 4/5+ 7/8-
1 Passive PoE-out RJ45 Port:
10/100/1000Mbps Auto-Negotiation
Voltage: depending on the input voltage of PoE-in ports
Power pin of Ethernet cable: 4/5+ 7/8-
1 DC Output Port:
Voltage: 5/12 V
Mounting Desktop/Wall Mounting
Performance
Switching Capacity 16 Gbps
Forwarding Rate 11.9 Mpps
MAC Address Table 4K
Jumbo Frame 16 KB
Physical &
Environment
Maximum Power
Consumption
3.98 W (no PD connected)
18.01 W (24 V voltage with PD connected)
32.74 W (48 V voltage with PD connected)
Maximum Heat
Dissipation
13.57BTU/h (no PD connected)
61.41BTU/h (24 V voltage with PD connected)
111.64BTU/h (48 V voltage with PD connected)
Dimensions (W×D×H) 6.2 x 3.9 x 1.0 in. (158 x 99.1x 25 mm)
Fan Quantity Fanless
Operating Temperature 0 °C–40 °C (32 °F–104 °F)
Storage Temperature -40 °C–70 °C (-40 °F–158 °F)
Operating Humidity 10%–90%RH, non-condensing
Storage Humidity 5%–90%RH, non-condensing
Certication CE, FCC
158 mm
99.1 mm
25 mm
DC Output Port 5V 12V /
Voltage Switch
7 × Passive PoE-in RJ45 Ports 1 × Passive PoE-out RJ45 Port
Software Features
Model RP108GE V1.20
L2 Features
• IGMP Snooping
• Static Link Aggregation
• Port Mirroring
• Loop Prevention
VLAN
• 32 VLANs (out of 4K VLAN IDs)
• MTU/Port/802.1Q VLAN
QoS
• 4 Priority Queues
• 802.1p/DSCP QoS
• Rate Limit
• Storm Control
Management
• Web-based Graphic User Interface (GUI)
• Easy Smart Conguration Utility
Disclaimers:
1. When the reverse switch functions, do not use the alternation switch to change output voltage of the DC output port, and do not plug
in or plug out cables connected to port 1–8.
2. It is recommended to use PoE injectors with overcurrent protection.
3. The input voltage of PoE-in ports should be higher than 18 V and lower than 51 V.
4. When the input voltage of port 1–7 is 24 V (±5%), the total output power should be ≤10 W, the maximum output current of DC out is 1.2
A/5 V and 0.8 A/12 V. When the input voltage of port 1–7 is 48 V (±5%), the total output power should be ≤ 26 W, the maximum output
current of DC out is 0.9 A/5 V and 1.0 A/12 V.
5. The device connected to port 8 should support passive PoE, otherwise, the impedance between pair 4&5 and pair 7&8 should be
higher than 1 MΩ.
Some models featured in this guide may be unavailable in your country or region. Visit TP-Link website for local sales information: www.
tp-link.com.
Specications are subject to change without notice. TP-Link is a registered trademark of TP-Link Technologies Co., Ltd. Other brands
and product names are trademarks or registered trademarks of their respective holders. Copyright © 2024 TP-Link Technologies Co.,
Ltd. All rights reserved.
