Seite 1/4

Simple and Reliable Way

to Overcome the Distance

Limitations

Surveillance | Enterprise | Factory | Park |

WISP | Machine Room | and More

Media Converters and SFP/SFP+ Modules

Simple and Reliable Way to Overcome the Distance Limitations

Machine Room

TP-Link Fast Ethernet Media Converters are designed to address the needs of exible long-range surveillance

deployment with optical bers. It provides an economical path towards extending the distance of an existing network.

TP-Link oers 100 Mbps and 1000 Mbps media converters to realize reliable network connections, making the

long-distance network deployments of surveillance cameras in businesses, factories, and parks simpler.

Flexible Selections of Distance and Speed

A wide range of media converters are available, oering

dierent maximum transmission distances of between 2 km to

20 km. Dierent speeds provide exible deployment options.

Stable Network Transmission

The stability of ber transmission guarantees our stable

monitoring of sensitive areas and point-to-point

connections.

Enterprise Surveillance Park Surveillance Campus Surveillance

Ideal for Flexible Surveillance Deployment

Fiber

Ethernet Cable (Power and Data)

Ethernet Cable (Data Only)

IP Cameras

Media Converter

IP Cameras

Media Converter

Chassis

Switch

NVR

PoE Switch

Cost Eective Solution with WDM*

WDM (Wave Division Multiplexing) technology enables you to

transmit and receive data over one single ber strand instead

of two.

Innovative Combination of PoE and Fiber**

The PoE output port of media converter provides a direct

data and power connection to the IP camera, making

remote camera deployment easier and more convenient.

Product Picture

Model MC100CM MC110 MC111 MC112CS CS CS TL-F AC111 -20 TL-F BC111 -20 TL-FC111PB-20

Power Input 9V/0.6A 5V/0.6A 48V/0.5A

Fiber Ports 2× 100 Mbps iber SC F Ports

1× 100 Mbps iber SC F Port

Copper Ports

1× 10/100 Mbps RJ45 Port RJ45 Port1× 10/100 Mbps

Transmission Diatance 2 km 20 km 20 km

Fiber Type Multi-Mode Singl Single-Mode e-Mode

Fiber Number

Dual ibers Single F Fiber Single iberF

Wave Length 1310 nm

TX: 1550 nm

RX: 1310 nm

TX: 1310 nm

RX: 1550 nm

TX: 1550 nm

RX: 1310 nm

TX: 1310 nm

RX: 1550 nm

TX: 1310 nm

RX: 1550 nm

Dimensions (W × D × H)

3.7×2.9×1.1 in (94.5×73.0×27.0 mm)

Operating Temperature 0–40˚C (32–104˚ ) 0–50˚C (32–122 ˚ )F F

Environment

Storage Tempe atur re: -40–70˚C (-40–158˚ )F

Oper t -Condensing; Stor t -Condensingating Humidi y: 10–90% RH Non age Humidi y: 5–90% RH Non

TP-Link 100 Mbps Media Converters at a Glance

1× 100 Mbps SC F iber Port

1× 10/100 Mbps

RJ45 PoE Port

100 Mbps Media Converters Benet Flexible Surveillance

Product Picture

Model MC200CM MC210 MC220LCS TL-F A TL-F B TL-F A TL-F BC311 -2 C311 -2 C311 -20 C311 -20

Power Input 9V/0.6A 5V/0.6A

Fiber Ports 2 × 100/1000 Mbps iber SC F Ports Port1 × Gigabit SFP

1× 100/1000 Mbps iber SC F Port

Copper Ports 1× 10/100/1000 Mbps RJ45 Port RJ45 Port 1× 10/100/1000 Mbps

Transmission Diatance 550 m 20 km

Depends on the used

SFP module

2 km 20 km

Fiber Type Multi-Mode Singl Single-Mode e-Mode

Fiber Number Dual ibers Single iberF F

Wave Length 850 nm 1310 nm

TX: 1550 nm

RX: 1310 nm

TX: 1310 nm

RX: 1550 nm

TX: 1550 nm

RX: 1310 nm

TX: 1310 nm

RX: 1550 nm

Dimensions (W × D × H) 3.7×2.9×1.1 in (94.5×73.0×27.0 mm)

Operating Temperature 0–40˚C (32–104˚ ) 0–50˚C (32–122 ˚ )F F

Environment

Storage Tempe atur re: -40–70˚C (-40–158˚ )F

Oper t -Condensing; Stor t -Condensingating Humidi y: 10–90% RH Non age Humidi y: 5–90% RH Non

Gigabit Media Converters—Long-Range Connections with Fiber

TP-Link Gigabit Media Converters easily extend the distance of an existing gigabit network. Long-range point-to-point

connections are easily built with the gigabit ber converters, making them ideal for connecting the network in another

building, remote surveillance system, and automated factory equipment.

*Certain media converters are equipped with WDM technology and use single ber to transmit and receive data.

**Only TL-FC111PB-20 is equipped with PoE output port.

TP-Link Gigabit Media Converters at a Glance

Enterprise Networks Manufacturing Equipment Surveillance Networks

Fiber

Ethernet Cable

Fiber

Ethernet Cable (Data Only)

Fiber Connections

between Enterprises

Media Converter

Chassis

L2+ Managed Switch

Machine Room

Building A

Fiber Connections for

Surveillance System

Unmanaged

Switch

Media

Converter

Unmanaged

Switch

Media

Converter

Building B

Ethernet Cable (Power and Data)

TL-MC1400



Up t Co erter Unitso 14 Media nv



9 VDC / 0.6 A Power Output



R Pedundant ower Supply



Hot-Swappable



Mounted Three Cooling Fans for Better Ventilation

TL-FC1420

Machine Room

Media Converter

IP Cameras

Media

Converter

Chassis

Switch

NVR

PoE Switch



Up t Co erter Unitso 14 Media nv



5 VDC / 0.6 A Power Output



R Pedundant ower Supply



Hot-Swappable



Mounted One Cooling Fan

Power Chassis—Ensure the Scalability of Installation

Produktspezifikationen

Marke:	TP-Link
Kategorie:	Audio/Video-Konverter
Modell:	TL-FC111A-20
Breite:	94.5 mm
Tiefe:	73 mm
Produktfarbe:	Schwarz
Übertragungstechnik:	Kabelgebunden
Höhe:	27 mm
Betriebstemperatur:	0 - 50 °C
Relative Luftfeuchtigkeit in Betrieb:	10 - 90 %
Verpackungsbreite:	165 mm
Verpackungstiefe:	204 mm
Verpackungshöhe:	65 mm
Paketgewicht:	360 g
Netzstandard:	IEEE 802.3, IEEE 802.3i, IEEE 802.3u
Zertifizierung:	FCC, CE
Anzahl Ethernet-LAN-Anschlüsse (RJ-45):	1
Warentarifnummer (HS):	85176990
Maximale Datenübertragungsrate:	100 Mbit/s
Ethernet LAN Datentransferraten:	10, 100 Mbit/s
Eingebaut:	Nein
LED-Anzeigen:	Activity, Link, Power
Temperaturbereich bei Lagerung:	-40 - 70 °C
Luftfeuchtigkeit bei Lagerung:	5 - 90 %
Auto MDI/MDI-X:	Ja
Kupfer Ethernet Verkabelungstechnologie:	10BASE-T, 100BASE-T
Ausgangsstrom:	0.6 A
Ausgangsspannung:	5 V
Nachhaltigkeitszertifikate:	RoHS
Maximal mögliche Übertragungsstrecke:	20000 m
Auto-Negotiation-Funktion:	Ja
unterstütze Kabeltypen:	Cat3, Cat4, Cat5, Cat5e
Unterstützung Datenflusssteuerung:	Ja
Wellenlänge:	- nm
Optischer Kabelverbinder:	SC
Unterstützte Faserkabeldurchmesser (Kern/Mantel):	9/125 µm
Kabel mode struktur:	Einzelmodus
Ethernet-Kabel Verkablungstechnologie:	100BASE-FX
Anzahl Faseranschlüsse:	1
Duplex-System:	Full, Half
