PAGE 1 OF 300525 IH-1114

1-800-295-5510

uline.com

π

INDUSTRIAL COUNTING

SCALE

H-1114, H-1115

H-1116, H-1117

For best performance, the scale should be located in

a cool, dry place that is free from excessive air currents,

corrosives, vibration and temperature or humidity

extremes.

WARNING! DO NOT place the scale:

• Next to open windows or doors.

• Near air-conditioning or heating vents.

• Near vibrating, rotating or reciprocating

equipment.

• Near magnetic fields or equipment

generating magnetic fields.

• On an unstable work surface.

• In dusty locations.

• In direct sunlight.

PREPARING TO USE THE SCALE

1. Put the scale on a firm, level surface to obtain

accurate weight readings.

2. Adjust the four leveling feet so scale platform is level.

3. Avoid placing scale in direct sunlight or near the

ventilating system exhaust port.

4. Before turning scale on, remove any weight on the

scale platform.

5. Once scale is turned on, it goes through an LCD test

and re-zeros.

6. Please allow scale to warm up 15-20 minutes before use.

7. When appears on screen, scale needs

recharging.

8. Place items being weighed in center of the platform

for accurate weighing. Overall dimensions of the

item should not exceed the platform dimensions.

RECHARGEABLE BATTERY

Powered by 115 VAC or rechargeable battery.

Scale operates up to 120 hours on a fully charged

battery. Recharge the battery when the appears

or every three months when the scale is not being used

for long periods of time.

BEFORE USING THE COUNTING SCALE

ACTIVATE SCALE

LEVEL THE SCALE

• Place the scale on a flat, level surface.

• Using the leveling bubble on the left front panel,

adjust the legs under scale until bubble is centered.

• TURN SCALE ON

• Nothing should be on the scale.

• Press ON/OFF located under the left side of the scale.

• Scale counts down to zero and displays the version

on the WEIGHTdisplay.

• Allow scale to warm up for 15 to 20 minutes before use.

Pcs

M

+

QUANTITY

STABLE

WEIGHT

UNIT WEIGHT

lb/1000

1-800-295-5510

8

7

9

4

5

6

1

2

3

0

.

CE

TARE

TOTAL

TOTAL

ZERO

UNIT

WT

SMPL

UNIT

WT

PST

7SMPL

QTY

PST

CHARGING

Para Español, vea páginas 11-20.

Pour le français, consulter le pages 21-30.
