USL, Inc.
JSD-80 Instruction Manual
Page 1
3rd Edition. February, 2006
1. Introduction
....................................
3
1.1 Safety notice
1.2 Unpacking
1.3 The JSD-80 Overview
1.4 Technical Specifi cations
1.5 Certifi cations
2. Installation
......................................
9
2.1 System Hardware Mounting
and Grounding
2.2 System Cooling and Ventila-
tion
3. Block Diagrams
............................
10
3.1 Audio Block Diagram
3.2 Two-Channel Analog Inputs
Block Diagram
3.3 Eight-Channel Input Block
Diagram
3. Control Block Diagram
4. System Modules
...........................
14
4.1 Input Module
4.2 Output Module
4.3 Control Module
5. Front Panel
....................................
15
5.1 Overview
5.2 Adjusting Format Levels
5.3 Adjusting Projector Gains
6. Back Panel
....................................
16
6.1 Rear Wiring Diagram
6.2 Back Panel Input Connec-
tions
6.3 Back Panel Signal Output
Connections
6.4 Other Back Panel Connec-
tions
7. JSD-80 Interface Software
............
19
7.1 Installation Procedure
7.2 Opening screen
7.3 Profi le Screen
7.4 Formats Screen
7.5 Inputs Screen
7.6 Equalizer Screen
7.7 Outputs Screen
7.8 Slit Eq Analyzer
7.9 Creating, Saving and Loading
Confi guration Files
8. “A” Chain Alignment
....................
23
8.1 Preparing the Soundhead
8.2 Alignment of Solar Cell and
Preamplifi er
8.3 Sum and Difference Mode
8.4 Mono EQ and Bypass Level
8.5 Optical Surround Gain and
Delay
8.6 Optical Subwoofer
8.7 Analog Non-Sync, Aux and
Mic levels
8.8 Digital Non-Sync, Digital Aux,
and Digital eight-channel
inputs
8.9 Digital Time Delays
9. “B” Chain Alignment
....................
29
9.1 Channel confi guration
9.2 Headroom settings
9.3 Main channels
9.4 Subwoofer channel
9.5 Saving Settings After Align-
ment
10. Other Options
..............................
33
10.1 Pre-set Format Levels
10.2 Startup Mode
10.3 Remote Fader
10.4 System Restore from Person-
ality Module
11. Trouble Shooting
.........................
35
12. Connector Pinouts
.......................
38
13. Installation Check List
.................
39
Table Of Contents
JSD-80
Cinema Sound Processor
USL, Inc.
JSD-80 Instruction Manual
Page 2
3rd Edition. February, 2006
One Year Limited Warranty
★★★★★
USL, Inc. warrants that each product manufactured by it will be free
from defects in material and workmanship under normal usage for
a period of one (1) year after its purchase new from an authorized
dealer. Our obligation under this warranty is limited to repairing or
replacing any product or component which we are satisfi ed does not
conform with the foregoing warranty and which is returned to our fac-
tory, freight paid, or serviced by one of our authorized contractors.
The foregoing warranty is exclusive and in lieu of all other warranties,
whether expressed or implied. Such warranty shall not apply to any
product or component (A) repaired or altered by anyone other than
USL, Inc. or an authorized service contractor; (B) tampered with or
altered in any way or subjected to misuse, negligence or accident
or (C) which has been improperly connected, installed or adjusted
other than in accordance with USL, Inc. instruction.
