Lies die bedienungsanleitung für V-TAC VT-44012 (3 Seiten) kostenlos online; sie gehört zur Kategorie Beleuchtung. Dieses Handbuch wurde von 2 Personen als hilfreich bewertet und erhielt im Schnitt 5.0 Sterne aus 1.5 Bewertungen. Hast du eine Frage zu V-TAC VT-44012 oder möchtest du andere Nutzer dieses Produkts befragen? Stelle eine Frage
Seite 1/3
PRODUCT
WEIGHT
DIMENSION
OPERATION
TEMPERATURE
MAX
MOUNTING
HEIGHT
PROJECTED
AREA(M²)
＜5 m130g 30-40
60-75
40-50
1640g
820g
＜5 m
＜5 m
100-125
150-200
180g
375g176x152x25mm
96x90x25mm
375x310x30mm
253x225x29mm
116x106x25mm
＜5 m
＜5 m
VT-44022
VT-44054
VT-44012
23971, 23972
23973, 23974
10W 730 lm 110° 20,000 ≥80≥0.9
AC: 220-240V,
50/60Hz
-20° to +40°C
-20° to +40°C
-20° to +40°C
-20° to +40°C
-20° to +40°C
AC: 220-240V,
50/60Hz
AC: 220-240V,
50/60Hz
AC: 220-240V,
50/60Hz
AC: 220-240V,
50/60Hz
≥80
≥80
≥80
≥80
≥0.9
≥0.9
≥0.9
≥0.9
20,000
20,000
20,000
20,000
110°
110°
110°
110°
16450 lm
8150 lm
1510 lm
4000 lm
200W
100W
23975, 23976
23977, 23978
23991
23979, 23980
23981, 23982
23992
23983, 23984
23985, 23986
23987, 23988
23989, 23990
23995
VT-44208
VT-44109
20W
50W
INPUT
VOLTAGE
CRIDF
LIFE
SPAN
[HOURS]
BEAM
ANGLE
USEFUL
LUMENS
WATTSMODEL SKU
INTRODUCTION & WARRANTY
TECHNICAL DATA
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions carefully
before starting the installing and keep this manual handy for future reference. If you have any another query, please
contact our dealer or local vendor from whom you have purchased the product. They are trained and ready to serve you
at the best. The warranty is valid for 2 years from the date of purchase. The warranty does not apply to damage caused by
incorrect installation or abnormal wear and tear. The company gives no warranty against damage to any surface due to
incorrect removal and installation of the product. The products are suitable for 10-12 Hours Daily operation. Usage of prod-
uct for 24 Hours a day would void the warranty. This product is warranted for manufacturing defects only.
INSTRUCTION MANUAL
LED FLOOD LIGHT
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
• Please make sure to turn o the power before starting the installation.
• Installation must be performed by a qualified electrician.
• The light source of this luminaire is not replaceable; when the light source
reaches its end of life the whole luminaire shall be replaced.
• The external flexible cable or cord of this luminaire cannot be replaced; if
the cord is damaged, the luminaire shall be destroyed.
• Terminal block not included.
• Must be connected to waterproof terminal box
• Proper grounding should be ensured throughout the installation.
• For outdoor use.
• Replace any cracked protective shield.
• Minimum distance from lighted objects 1m.
Wire Length : 120mm
INSTALLATION DIAGRAM
WARNING
NOTE
• To reduce the risk of strangulation the flexible wiring connected to this luminaire shall be eectively
fixed to the wall if the wiring is within arm's reach.
• In order to maintain the IP protection of the product, the cable entry/gland should be installed on the
bottom side.
This marking indicates that this
product should not be disposed
of with other household wastes.
Caution, risk of electric shock.
1
4
5
2
3
Brown — L
Blue — N
Yellow green —
Non-replaceable light source
Non-replaceable control gear
INSTALLATION INSTRUCTION
Strictly follow these instructions for installing, avoid the intensity of power cable during installing.
( Supply connection and other external wiring conductor shallbe at least 3*1.0 mm2 and confirm
to 60245IEC57 )
V-TAC UK LTD. IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT PLEASE REACH OUT TO US AT
SUPPORT@VTACEXPORTS.COM V-TAC, 5A TUNGSTEN PARK, DOWNS ROAD, WITNEY, OXFORDSHIRE, OX29 0AX
V-TAC WEST EUROPE LTD. IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT:
SUPPORT@V-TAC.EU FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC WEST EUROPE LTD. GROUND FLOOR, 71 LOWER BAGGOT STREET, DUBLIN 02, IRELAND DO2 P593
1. Turn o the power before starting the installation.
2. Install the brackets securely in place.
3. Adjust the flood light to achieve the desired angle.
4. Secure the flood light firmly in the chosen position.
5. Connect the wires as per the diagram provided.
6. Turn on the power and test the light.
