1

VESTIL MANUFACTURING CORP.

2999 North Wayne St.,Angola,IN46703

Ph: 260-665-9521 Fax: 260-665-1339

SAFETYGUIDELINES:

Material handling is dangerous. To reduce the

likelihood of injury to person or property:

•Read thismanual in its entirety before installing,

using and maintaining this table for the first time!

•Thecapacityofyourtableisbasedonauniformly

distributed,centeredload.DONOTexceedthe

capacitybecausepermanentdamageand/orpersonnel

injurycouldresult.Contactthefactoryforside-loading

andend-loadingcapacities.

•DONOTlowertheunitontothemaintenanceprop(s)

whilethetableisloaded.

•DONOTgoundertheplatformunlessthe

maintenancepropisinposition.

•ONLYuseAW-32hydraulicoil(orequivalent),or

DexronIItransmissionfluidinthetablesreservoir.Do

notusebrakefluidsorjackoils.

•Checkthesettingsandconditionsofallsafety

switches andstickersfrequently.

•Neveroperatethetableifit(oranycomponent)is

inneedofrepair.Tag the unit "Out-of-service" and

notifymaintenancepersonnelif, during operation,any

unusualnoises,movements,or noticeabledamageto

theunderstructureof controls,orifthetablefails to

respondnormallyto control commands.

OPERATION

The table is equipped with a "deadman"

stylepush

button controler. This type of operation,

also called "push-to- run", allows the operator to

move the deck of the table as much or as little as

necessary.

The air motor of the power unit requires a

minimum air supply of 70 CFM at 70 PSI.

AHLT-SERIES

AIRHYDRAULICSCISSORTABLES

OWNER'SMANUAL

Revised 11-13

A company dedicated to solving ergonomic

and materialhandling problems since1955.

AIRHYDRAULIC SCISSOR TABLE MODEL AHLT

Website: www.vestil.com

Ergonomic Solutions

Contents

Safety Precautions.......................................... 1

Operation .................................................. 1 & 4

Installation Instructions.................................... 2

Pneumatic/Hydaulic CircuitDiagrams..............3

Loading Instructions........................................ 4

Pneumatic/Hydraulic Diagram......................... 5

Exploded Parts Drawing............................... 6

Parts List....................................................... 7

Troubleshooting Guide........................... 8 & 9

Inspections & Maintenance........................10

Labelplacementdiagram............................11

Limited Warranty.........................................12

RECEIVING INSTRUCTIONS:

After delivery, IMMEDIATELY remove the packaging

from the product in a manner that preserves the

packaging and maintains the orientation of the product

in the packaging; then inspect the product closely to

determine whether it sustained damage during

transport. If damage is discovered during the inspection,

immediately record a complete description of the

damage on the bill of lading. If the product is

undamaged, discard the packaging.

NOTES:

1) Compliance with laws, regulations, codes, and non-

voluntary standards enforced in the location where the

product is used is exclusively the responsibility of the

owner/end-user.

2) VESTIL is not liable for any injury or property damage

that occurs as a consequence of failing to apply either:

a) the instructions in this manual; or b) information

provided on labels affixed to the product. Neither is

Vestil responsible for any consequential damages

sustained as a result of failing to exercise sound

judgment while assembling, installing, using or

maintaining this product
