Table of ContentsRev. 5/28/2025 AHSN, MANUAL

Table of ContentsVestil Manufacturing Co. Page 1 of 26

AHSN-Series Knockdown, Steel, Adjustable-Height Cranes

Receiving Instructions

After delivery, remove the packaging from the product. Inspect the product closely to determine

whether it sustained damage during transport. If damage is discovered, record a complete description

of it on the bill of lading. If the product is undamaged, discard the packaging.

NOTE:The end-user is solely responsible for confirming that product design, use, and maintenance

comply with laws, regulations, codes, and mandatory standards applied where the product is used.

Technical Service & Replacement Parts

For answers to questions not addressed in these instructions and to order replacement parts, labels,

and accessories, call our Technical Service and Parts Department at (260) 665-7586. The department

can also be contacted online at https://www.vestil.com/page-parts-request.php.

Electronic copies of Instruction Manuals

Additional copies of this instruction manual may be downloaded from https://www.vestil.com/page-

manuals.php.

Vestil Manufacturing Co.

2999 North Wayne Street, P.O. Box 507, Angola, IN 46703

Telephone: (260) 665-7586 -or-Toll Free (800) 348-0868

Fax: (260) 665-1339

www.vestil.cominfo@vestil.com

Table of Contents

Page

Table of Figures

Page

Specifications…………………

2, 3

Fig. A Exploded View: AHSN-2-10-12, 2-10-14, & 2-10-16…

5

Signal Words……..……………

4

Fig. B Exploded View AHSN-2-15 series…………..…….….…

6

Safety Instructions………..…..

4

Fig. C Exploded View AHSN-2-20-12, 2-20-14, & 2-20-16.…

7

Assembling the Crane…........

18, 19, 20, 21

Fig. D Exploded View AHSN-4-10-12, 4-10-14, & 4-10-16.…

8

Using the Crane…..…………..

22, 23

Fig. E Exploded View AHSN-4-15 series…….…………………

9

Festoon Kit……………………..

23

Fig. F Exploded View AHSN-4-20-12, 4-20-14, & 4-20-16..…

10

Record of Satisfactory

Fig. G Exploded View AHSN-6-10-12, 6-10-14, & 6-10-16.…

11

Condition…………………..…..

24

Fig. H Exploded View AHSN-6-15 series………………………

12

National Standards…………..

24

Fig. I Exploded View AHSN-6-20-12, 6-20-14, & 6-20-16...…

13

Inspections & Maintenance..

24

Fig. J Exploded View AHSN-8-10-12, 8-10-14, & 8-10-16…..

14

Labeling Diagram….…………

25

Fig. K Exploded view AHSN-8-15 series………………….……

15

Limited Warranty…………......

26

Fig. L Exploded view AHSN-8-20-12, 8-20-14, & 8-20-16…...

16

Fig. M Exploded view AHSN-10-15-10…………………...……

17
