TABLE OF CONTENTSRev. 11/23/2021 EHLTP MANUAL

TABLE OF CONTENTSCopyright 2020 Vestil Manufacturing Corp. Page 1 of 26

EHLTP-Series Portable Electric-Hydraulic Lift Tables

Receiving Instructions

After delivery, remove the packaging from the product. Inspect the product closely to determine

whether it sustained damage during transport. If damage is discovered, record a complete description of

it on the bill of lading. If the product is undamaged, discard the packaging.

NOTE:The end-user is solely responsible for confirming that product design, use, and maintenance comply

with laws, regulations, codes, and mandatory standards applied where the product is used.

Technical Service & Replacement Parts

For answers to questions not addressed in these instructions and to order replacement parts, labels,

and accessories, call our Technical Service and Parts Department at (260) 665-7586. The Department can

also be contacted online at https://www.vestil.com/page-parts-request.php

.

Electronic Copies of Instruction Manuals

Additional copies of this instruction manual may be downloaded from

https://www.vestil.com/page-

manuals.php.

Vestil Manufacturing Corp.

2999 North Wayne Street, P.O. Box 507, Angola, IN 46703

Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868

Fax: (260) 665-1339

Web:

www.vestilmfg.come-mail: info@vestil.com

Table of Contents

Page

Signal Words……………………..…………………………….……………………………..……….………….….

2

Safety Instructions………….……………………………………………………..…………..……….…………...

2 - 3

Hydraulic Circuit Diagram………..…………...……………………..………………………..………………….

3

Exploded Views and Bills of Materials………………………………………………………..…………………

4 - 15

Power Unit Subassemblies………………………………………………………………………………….……..

16, 17, 18

Exploded View and Bill of Materials: Perimeter Toeguard………………………………..……………...…

19

Specifications………………………………………………………………………………………..………………

19

Record of Satisfactory Condition………………………………………………………………….…………....

20

Operation Instructions………………………………………………………………………………..………...….

20, 21

Inspections and Maintenance……………………………………………………………………….……….…

21, 22, 23

Bleeding Air from the Hydraulic Cylinder…………………………………………………………..….……….

23

Troubleshooting Guide…………………………………………………………………………….……..…..……

24

Labeling Diagram.…………..………………………………………..……………............................................

25

Limited Warranty…………………………………………….……………………………………………..…....…

26
