Table of ContentsRev. 11/30/2018 LAD-FM, MANUAL

Table of ContentsCopyright 2017 Vestil Manufacturing Co.Page 1 of 18

LAD-FM Mezzanine Ladders

Instruction Manual

Receiving instructions:

After delivery,remove the packaging from the product. Inspect the product closely to determine

whether it sustained damage during transport. If damage is discovered, record a complete

description of it on the bill of lading. If the product is undamaged, discard the packaging.

NOTE:The end-user is solely responsible for confirming that product design, use, and maintenance

comply with laws, regulations, codes, and mandatory standards applied where the product is used.

Replacement Parts and Technical Assistance:

For answers to questions not addressed in these instructions and to order replacement parts,

labels, and accessories, call our Technical Service and Parts Department at (260) 665-7586. The

department can also be contacted online at http://www.vestilmfg.com/parts_info.htm

.

Table of Contents

Signal words…………………………………………………………..……………………………………. …. 2

Hazards of using the stair system……………………………….……………….……..……………........... 2

Specifications…………….…………………..…………………………………...……………..…………. …. 3

FIG. 1: LAD-FM-60 exploded parts diagram and bill of materials…………………………………….. …. 4

FIG. 2: LAD-FM-72 exploded parts diagram and bill of materials…………………………………….. …. 5

FIG. 3: LAD-FM-84 exploded parts diagram and bill of materials…………………………………….. …. 6

FIG. 4: LAD-FM-96 exploded parts diagram and bill of materials…………………………………….. …. 7

FIG. 5: LAD-FM-108 exploded parts diagram & bill of materials……………………………………… …. 8

FIG. 6: LAD-FM-120 exploded parts diagram & bill of materials……………………………………… …. 9

FIG. 7: Jack Assembly…………………………………………………………………………………….. …. 10

Installation……………..……………………………………………………………………………….….... 10-15

Storage………………………………………………………………………………………………...……. …. 16

Extending the stair system……………………………………………………………………………………. 16

Putting the stair system into stored position without using the jack………………………………………. 16

Record of normal condition……………………………………………………………………………………. 16

Inspections …………………..…………………………………………………………………………………. 17

Labeling diagram…………………………………………………………………………………………… …. 17

Limited warranty……………………………………………………………………………………………. …. 18

Vestil Manufacturing Corp.

2999 North Wayne Street, P.O. Box 507, Angola, IN 46703

Telephone: (260) 665-7586 -or-Toll Free (800) 348-0868

Fax: (260) 665-1339

Website: www.vestilmfg.come-mail: info@vestil.com
