01/11 Rev. 8/28/2024 LM, MANUAL

Table of ContentsCopyright 2020 Vestil Manufacturing Co. Page 1 of 25

LM-Series Fork Truck Attachments

Receiving Instructions

After delivery, remove the packaging from the product. Inspect the product closely todetermine

whether it sustained damage during transport. If damage is discovered, record a complete description of

it

on the bill of lading. Ifthe product is undamaged, discard the packaging.

NOTE: The end-user is solely responsible for confirming that product design, use, and maintenance

comply with laws, regulations, codes, and mandatory standards applied where the product is used.

Technical Service & Replacement Parts

For answers to questions not addressed in these instructions and to order replacement parts, labels,

and

accessories, call our Technical Service and Parts Department at (260) 665-7586. The department

can also

becontacted online athttps://www.vestil.com/page-parts-request.php.

Electronic copies ofInstruction Manuals

Additional copies of this instruction manual may be downloaded from https://www.vestil.com/page-

manuals.php

LM-HRT &

LM-HRNT

Vestil Manufacturing Co.

2999 North Wayne Street, P.O. Box 507, Angola, IN 46703

Telephone: (260) 665-7586 -or-Toll Free (800) 348-0868

Fax: (260) 665-1339

Web: www.vestil.come-mail: [email protected]m

LM-1T &

LM-1NT

LM-OBT &

LM-OBNT

Table of Contents

Page

Signal Words…………….…………………………………………………………………………………….…

2

Safety Instructions……………………………………………………………………………………………...…

2

National Standards……..………………………………………………………………………………………..

2

Fig. 1: LM-1T & -1NT Exploded Views, Parts Lists, Centers of Gravity………………………………..…

3, 4, 5, 6

Fig. 2: LM-OBT & -OBNT Exploded Views, Parts Lists, Centers of Gravity.............................................

7, 8, 9, 10

Fig. 3: LM-HRT & -HRNT Exploded Views, Parts Lists, Centers of Gravity………………………………..

11, 12, 13, 14

Fig. 4: LM-EBT & -EBNT Exploded Views, Parts Lists, Centers of Gravity...............................................

15, 16, 17, 18

Loading & Using the Boom……………………………………………………………………………………..

19, 20, 21

Record of Satisfactory Condition……………………………………………………………………….…….

21

Load Tests…………………………………………………………………………………………………….……

21

Inspections…………………..……………………………………………………………………………………...

22

Maintenance……………….………………………………………………………………………………………

22

Labeling Diagram……….……………………………………………………………………………………...…

23

Limited Warranty…………..……..………………………………………………………………………………..

24

Load Test Record…………………………………………………………………………………………….....…

25

NOTE: MODELS LM-EBT & EBNT NOT SHOWN.
