Thank you for purchasing a genuine Z-WAGZ unit, the simplest Plug & Play mod

comes pre-programmed with 3 different light patterns, some for halogen systems & some for LED systems.

Operation for all GM trucks is the same :

1.Install the Z-WAGZ unit to the OE Light Control Module. Follow instructions on page 2 for more d

information.

2.Turn Ignition ON or start vehicle (Ignition must be on for proper operation)

3.To activate Z-WAGZ:

oPress and HOLD the lever (5 sec) high beamOR

oPress and HOLD the provided push button (3 sec) OR

oSend a (+) signal to the (designed to be extended for OE -fitter switches12vblue wireup

toggle) OR

oPress LOCK>UNLOCK>LOCK>UNLOCK on the key fob (dip switch 6 must be ON, ignition is NOT required for

this method)

Pattern 1 will begin to flash. Once pattern 1 begins, the turn signal indicators in the gauge cluster will blink 1 time then stay

solid, indicating Pattern 1 has been selected. The LED on the unit will blink . BLUESee chart on page 4 for remaining pattern

color indication.

4.To switch to Pattern 2: (Pattern 1 must be currently active)

oEngage either turn signal, then press and HOLD the lever once more (5 sec)high beam. OR

oPress & release the provided push button one time

The turn signals will blink twice (then stay solid) indicating Pattern 2 has been selected. Repeat this process to switch to t

next pattern.

5.To deactivate Z-WAGZ:

oPress and HOLD the lever (5 sec) high beamOR

oPress and HOLD the provided push button (3 sec) OR

oRelease (+) signal to the (if connected this way) 12vblue wireOR

oTurn vehicle OFF

GENERAL NOTES:

•Disconnecting the attached 120 OHM resistor from the 2-pin harness is for higher-equipped trims (example:

with SuperCruise).

•Vehicles equipped with LED lights should use LED patterns. Vehicles equipped with standard bulbs should

use bulb patterns but may get away with LED patterns (although some consistency may be lost).

•Not all lights on the vehicle are necessarily used, some lights are not controllable via CAN data commands.

•Z-WAGZ will retain the last used pattern, even after being disconnected from the harness (if ever) .

•Turn signals, headlights & reverse lights will override pattern flashing when used, until turned off again .

•Lights on the external mirrors will only flash if connected with turn signals.

•‘Plow Mode’, when active (INPUT 2), disables High & Low beam flashing and slows the pattern down so that

the relay box (plow module) can keep up with the flashing (prevents overheating).

Activation Switch

and I/O Harness

ZW- GMLCv2

T-Harness
