BATH AND SHOWER TRIM KIT

M965054 REV.1.2 (3/15)

To assure proper positioning in relation to wall,

note roughing-in dimensions.

ROUGHING-IN DIMENSIONS

Certified to comply with ANSI A112.18.1

Installation

Instructions

T430.507

T430.508

T431.507

T431.508

THREADED INLETS (STOPS)

INLETS

1/2" NPT

(13mm)

5-7/8"

(149mm)

INLETS 1/2" NPT (13mm}

OUTLETS

1/2" NPT

(13mm)

OUTLETS

1/2" NPT

(13mm)

3-3/8"

(86mm)

3-3/8"

(86mm)

3-3/8"

(86mm)

THREADED INLETS

Recommened Tools

Flat Blade Screwdriver

Adjustable Wrench

Channel Locks

Plumbers' Putty or Caulking

Phillips Screwdriver

4" (102mm)

BOTTOM OF TUB

74" FOR HEAD

CLEARANCE

(1880mm)

18" OPTIONAL

(457mm)

1/2" COPPER

OPTIONAL TO FINISHED

FLOOR USUALLY

BETWEEN 65'' AND 80''

(1651 and 2032mm)'

TOP OF TUB RIM

Teflon Tape

SHR. 1/2" NOM.(13mm)

COPPER SWEAT

TUB 1/2" NOM. (13mm)

COPPER SWEAT

4-1/16"

(103mm)

5-7/8"

(149mm)

INLETS

4-1/16"

(103mm)

4-1/16"

(103mm)

INLETS

1/2" NOM.

(13mm)

COPPER

SWEAT

SHR. 1/2" NOM.

(13mm)

COPPER SWEAT

TUB 1/2"

(13mm) NOM.

COPPER SWEAT

2"

SWEAT

INLETS

SWEAT

INLETS (STOPS)

INLETS

1/2" NOM.

(13mm)

COPPER

SWEAT

FINISHED WALL

Thank you for selecting American-Standard...the benchmark

of fine quality for over 100 years.

To ensure that your installation proceeds smoothly--please

read these instructions carefully before you begin.

BERWICK

®

/ BOULEVARD

®

1/2" NPT

(13mm)

1-5/8" to 3-1/4"

(41 to 83 mm)

1-5/8" to 3-1/4"

(41 to 83 mm)

5-5/8" REF.

(143mm)

8-1/8" REF.

(206mm)

2-3/8" D.

(60mm)

4-7/8" REF.

(124mm)

7-1/4"

(184mm)

1-3/4

"

(44 mm)
