5-5/8" REF.

T506.50X

To assure proper positioning in relation to wall, note

roughing-in dimensions.

ROUGHING-IN DIMENSIONS

Certified to comply with ANSI A112.18.1

Installation

Instructions

Recommended Tools

Flat Blade Screwdriver

Adjustable Wrench

Channel Locks

Plumbers' Putty or Caulking

Phillips Screwdriver

BOTTOM OF

TUB

74" FOR

HEAD CLEARANCE

FINISHED WALL

8-1/8" REF.

4"

6-1/2"

18"

OPTIONAL

TOP OF

TUB RIM

Pipe Wrench

BATH/SHOWER TRIM KIT

8-3/8"

2-3/8"

MOMENTS

THREADED INLETS (STOPS)

INLETS

1/2" NPT

5-7/8"

OUTLETS

1/2" NPT

3-3/8"

INLETS 1/2" NPT

OUTLETS

1/2" NPT

3-3/8"

3-3/8"

THREADED INLETS

INLETS

4-1/16"

4-1/16"

INLETS

1/2" NOM.

COPPER

SWEAT

SHR. 1/2" NOM.

COPPER SWEAT

TUB 1/2" NOM.

COPPER SWEAT

2"

SWEAT

INLETS

SHR. 1/2" NOM.

COPPER SWEAT

TUB 1/2" NOM.

COPPER SWEAT

4-1/16"

5-7/8"

SWEAT

INLETS (STOPS)

INLETS

1/2" NOM.

COPPER

SWEAT

"SEE ILLUSTRATION "

1/2" NPT

1-1/2" REF.

3/4"" TO 2-3/8"

SHR

TUB

OPTIONAL TO FINISHED

FLOOR USUALLY

BETWEEN 65'' AND 80''

M968951 Rev. 1.5

DO: SIMPLY RINSE THE PRODUCT CLEAN WITH CLEAR WATER. DRY WITH A SOFT COTTON FLANNEL CLOTH.

DO NOT: DO NOT CLEAN THE PRODUCT WITH SOAPS, ACID, POLISH, ABRASIVES, HARSH CLEANERS, OR A

CLOTH WITH A COARSE SURFACE.

CARE INSTRUCTIONS:

Thank you for selecting American-Standard...the benchmark

of fine quality for over 100 years.

To ensure that your installation proceeds smoothly--please

read these instructions carefully before you begin.

1/2" COPPER
