SERIN

™

T064.740

Installation

Instructions

M968984 REV.1.3 (12-14)

Thank you for selecting American-Standard...the benchmark

of fine quality for over 100 years.

To ensure that your installation proceeds smoothly--please

read these instructions carefully before you begin.

Certified to comply with ANSI A112.18.1M

ASSE 1016

ROUGHING-IN DIMENSIONS

Recommended Tools

Flat Blade Screwdriver

Phillips Screwdriver

Remove as much surface dirt and film using clear

water and soft cotton cloth (as described above).

Use any of the following to remove tough surface

film and build-up:

Mild liquid detergents

Clear ammonia free liquid glass cleaners

Non-acidic, non-abrasive gentle liquid or fully

dissolved powder cleansers mixed according to

manufacturers directions.

Non-abrasive liquid polishers

Once clean, rinse faucet again with clear water to

thoroughly remove cleaner or polish and blot dry with

a soft cotton cloth.

To keep your new faucet looking new, please follow

these simple care instructions:

DO: Simply rinse the faucet clean with clear water.

Dry the faucet with a soft cotton cloth.

DO NOT:

Do not use any abrasive cleaners, cloths, or

paper towels.

Do not use any cleaning agents containing

acids, polish abrasives, or harsh cleaners or

soaps.

Regular and routine cleaning will reduce the need for

heavy cleaning and polishing. If heavy cleaning is

required, the following procedures are recommended:

CARE INSTRUCTIONS:

Failure to follow these care instructions may

damage the Faucet's finish.

2-HANDLE THERMOSTAT

WITH VOLUME CONTROL

TRIM KIT

186mm

(7-3/8)

100mm

(3-7/8)

200mm

(7-7/8)

48mm to 68mm

(2 to 2-5/8)

150mm

(6)

NOTE: FITTING

MUST BE INSTALLED

WITH VOLUME CONTROL

ON TOP.

R520

1/2" NPT INLETS

or

R540

3/4" NPT INLETS

25mm

(1)

FINISHED

WALL

160mm

(6-1/4)
