- 1 -
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2020
Thank you for selecting American Standard...
the benchmark of ne quality for over 140 years.
To ensure that your installation proceeds smoothly-please
read these instructions carefully before you begin.
RECOMMENDED TOOLS AND MATERIALS
Most of the procedures require the use of common tools and materials, which are available from hardware and plumbing
supply stores. It is essential that the tools and materials be on hand before work is begun.
M985041 (3/20)
Spectra
Filter Shower Rail
ROUGHING-IN DIMENSIONS:
• For reference
3-5/16"
(84 mm)
3-7/16"
(86.7 mm)
Ø 7/8"
(22 mm)
5-7/16"
(138 mm)
1-1/2"
(38.7 mm)
FINISHED
WALL
60"
(1524 mm)
5-1/4"
(133 mm)
24"
(609 mm)
MIN. 1" – MAX. 2-5/16"
(25 – 58 mm)
DrillPhillips Head ScrewdriverLevel
10'
Tape Measure
Plumbers Tape
O-Ring Grease
CARE AND CLEANING
Do: Simply rinse the product clean with clear water, dry with a soft cotton flannel cloth.
Do Not: Clean the product with soaps, acid, polish, abrasives, harsh cleaners, or a cloth with a coarse surface.
INSTALLATION
INSTRUCTIONS
9238759.XXX
(24" Bar 1.8 gpm)
1 Cenntenial Avenue, Piscataway, New Jersey 08855
