Recommended Tools

Flat Blade Screwdriver

Adjustable Wrench

Channel Locks

Plumbers' Putty or Caulking

Phillips Screwdriver

Teflon Tape

Certified to comply with ANSI A112.18.1

ROUGHING-IN DIMENSIONS (For reference only)

To assure proper positioning in relation to wall, note roughing-in dimensions.

PRESSURE BALANCING

BATH AND SHOWER

TRIM KITS

M965471 Rev. 1.1

T184.50X Series

Installation

Instructions

1-5/8" TO 3-1/4"

(41 mm TO 83 mm)

BOTTOM OF

TUB

1/2" NPT

FINISHED WALL

1/2" COPPER

"SEE ILLUSTRATION"

TOP OF

TUB RIM

TUB

SHR

8-1/4"

(210 mm)

TIMES SQUARE

™

Thank you for selecting American-Standard...the benchmark

of fine quality for over 100 years.

To ensure that your installation proceeds smoothly--please

read these instructions carefully before you begin.

1-3/4" MIN.

(44 mm)

4-1/2"REF.

(114 mm)

7-1/2" REF.

(191 mm)

H

C

O

F

F

H

C

O

F

F

1/2" NPT

305mm

(12")

102mm

(4")

203mm SQ.

(8")

65mm

(2-1/2" Sq.)

65mm

(2-1/2" Sq.)

4-3/4"

REF.

(121mm)

OPTIONAL TO FINISHED

FLOOR USUALLY

BETWEEN 65'' (1651mm)

AND 80'' (1880mm)

4" (102 mm)

74" FOR HEAD

CLEARANCE

(188 cm)

18" OPTIONAL

(457mm)

INLETS 1/2" NPT

OUTLETS

1/2" NPT

3-3/8"

(98mm)

3-3/8"

(98mm)

THREADED INLETS (STOPS)

INLETS

1/2" NPT

OUTLETS 1/2" NPT

3-3/8" (98mm)

THREADED INLETS

SHR. 1/2" NOM.

COPPER SWEAT

TUB 1/2" NOM.

COPPER SWEAT

4-1/16"

(103mm)

4-1/16"

(103mm)

5-7/8"

(149mm)

5-7/8"

(149mm)

INLETS

4-1/16"

(103mm)

INLETS

1/2" NOM.

COPPER

SWEAT

SHR. 1/2" NOM.

COPPER SWEAT

TUB 1/2" NOM.

COPPER SWEAT

2"

(51mm)

SWEAT

INLETS

SWEAT

INLETS (STOPS)

INLETS

1/2" NOM.

COPPER

SWEAT
