INSTALLATION MANUAL – CMC Series Corner Mount Cameras

WARNING: Before beginning installation of this product, carefully review the safeguards and

precautions found on page 2 of this manual.

Unpacking

Unpack carefully. This is electromechanical

equipment and should be handled with care. If an

item appears to have been damaged in shipment,

replace it properly in its carton and notify the shipper.

If any items are missing, notify CBC (America) Corp.

The shipping carton is the safest container in which

the unit may be transported. Save it for possible

future use.

Service

If the unit ever needs repair service, the customer

should contact CBC (America) Corp. for a return

materials authorization (RMA) and shipping

instructions.

Care and Maintenance

Perform routine maintenance to keep the unit dust

free. Clean the viewing window as needed with a

damp, soft cloth.

Model Designation

CMC-25X Corner Mount Camera

Description

This camera can be mounted in any 90-degree corner

at any height desired. The unit includes four conduit

knockout holes to accommodate many installation

locations. The camera bracket can be adjusted to

attached the desired viewing angle.

Hardware Kit

2 x #10 Screws

2 x Plastic Drywall Anchors

Tools Required

Small adjustable wrench

Small Phillips head screwdriver (PH0 or smaller)

1/4” Drill Bit

5/32” Drill Bit

Certification

Installation should be performed by a licensed

professional and conform to the National Electrical

Code (NEC) and any applicable local codes.

Installation

1.The camera can be mounted securely in any 90-

degree corner at any height desired. Before

mounting the camera, determine the approximate

position and location required. Select the

appropriate fasteners for the type of mounting

surface. Also consider the cable entry path for

power and video cables to the camera’s location.

2.The camera provides four (4) mounting holes,

two (2) on the top, and two (2) on the sides. It

is recommended to use, at minimum, either the

two top or the two side mounting points. Two

(2) #10 fasteners with drywall anchors are

provided in the hardware kit. For other mounting

surfaces, verify the fastener type used will

provide the strength required for the installation.

3.The camera provides four (4) conduit knockouts,

two (2) on the top and two (2) on the sides.

After the cable path is determined, select the

appropriate knockout to use. Remove the

camera faceplate by removing the two visible

screws (front of camera). With the faceplate off,

carefully remove the selected knockout for cable

entry into the camera.

---------- Instructions continue on Page 3-----------
