Assembly Instructions: (Duncan)3602-1W
IMPORTANT:
•ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.
•SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!
•USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!
PREPARING FOR INSTALLATION
Remove all of the contents from the carton. See the important
notes above. Shut off the power at the circuit breaker and
completelyremovetheoldxturefromthewall,includingthe
oldmountingstrap.
Mountingstrap(B)containsseveralpairsofthreadedholes.
Findthepairofholesthatmatchesthespacingoftheholeson
thejunctionboxandyourxturebackplate.Twoofmounting
screws(A)shouldbeattachedtomountingstrap(B).You
mayneedtotightenthenutsthatholdthesescrewsinplace.
Pullthehousewiresthroughthecenterofmountingstrap
(B).Placemountingstrap(B)overthejunctionboxsothat
mountingscrews(A)arehorizontal,andinalignmentwiththe
holelocationsonthexturebackplate(G).Securemounting
strap(B)tothejunctionboxwithmountingscrews(D)anda
screwdriver.Tightenthescrewssecurely.
CONNECTING THE WIRES
Attachthexture’swirestothepowersupplywiresfromthe
junctionbox.Connectblacktoblack(orsmooth);whiteto
white(orribbed);groundtoground(greenorcopper).Twist
theendsofthewirepairstogether,thentwistonawire
connector. Make sure all twists are in the same direction. If
thereisnogroundwire(greenorcopper)fromthejunction
box,locategroundscrew(E)onmountingstrap(B)andwrap
thexturegroundwirearoundthegreengroundscrew(E).Use
ascrewdrivertosecuregroundscrew(E)ontothemounting
bracket.Tuckallwiresneatlyintothejunctionbox.
FINISHING THE INSTALLATION
Placexturebackplate(F)overmountingscrews(A)sothat
theyprotrudethroughtheholesinthefrontofthebackplate.
Threaddeconuts(G)ontomountingscrews(A).Twistuntil
backplate(F)ofthextureissnugagainstthewall.
Slide shade (I) onto socket (H) and secure with socket washer
(J)andsocketring(K).
Installthelightbulb(L)(notprovided)inaccordancewith
thexture’sspecications.Donotexceedthemaximum
recommendedwattage.
Your installation is now complete. Turn on the power and test
thexture.
CLEANING TIPS
Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the
xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture. For deep cleaning, turn off the light
and remove the glass prior to cleaning. Hand wash glass with warm water and mild detergent. Dry with a lint-free or microber cloth.
For Customer Service, contact
the place of purchase to arrange
for replacement parts.
BLACK
(Hot)
WHITE
(Neutral)
GREEN
(Ground)
HOUSE WIRES
SMOOTH
(Or Black)
FIXTURE WIRES
RIBBED
(Or White)
BARE COPPER
(Or Green)
C
B
E
D
A
F
G
L
H
I
J
K
