Assembly Instructions: 4309-SF (Mercer)

IMPORTANT:

•ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.

•SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!

•USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!

PREPARING FOR INSTALLATION

Remove all of the contents from the carton. See the important notes above. Remove the

oldxturefromtheceiling,includingtheoldmountingstrap.Thisxturemaybemounted

asapendantorushmount.Choosehowyouwouldliketomountthextureandfollow

thecorrespondinginstructions.

1.Fromthepartsbagremovethemountingstrapassembly.Mountingstrap(B)contains

holes.Twoofmountingscrews(A)shouldbeattachedtomountingstrap(B).Youmay

needtotightennuts(C)thatholdthesescrewsinplace.

2.Placemountingstrap(B)overthejunctionboxsothatmountingscrews(A)arevertical,

andinalignmentwiththelocationsoftheholesoncanopy(G).

3.Securemountingstrap(B)tothejunctionboxwithmountingscrews(D)anda

screwdriver.Tightenthescrewssecurely.

4.Centerrod(M)isonthewires,butnotconnectedtolampcluster(P).Youmayneedto

twistcenterrod(M)tightlyontothethreadsofposts(V)and(T).Threadthexture’swires

throughthecenterofswivel(H).Connectcenterpost(L)toswivel(H).Tightenscrew(I)to

secureinplace.Pullthewiresuntiltaut.

CLEANING TIPS

Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the

xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.

For Customer Service, contact

the place of purchase.

FINISHING THE INSTALLATION

6.Pushcanopy(G)uptotheceilingandtightlythreadnuts(F)ontotheexposedthreads

ofmountingscrews(A).

7.Slidecandlesleeves(U)overthesockets.Installlightbulbs(notprovided)in

accordancewiththexture’sspecications.Donotexceedthemaximumwattage.

8.Slideglassshade(O)followedbybottomcap(P)upoverthesocketcluster.

9.Threadspacer(Q)andbottomnial(R)ontothethreadsofbottompost(N)atthe

bottomofthelampclustertosecuretheglassinplace.

Yourinstallationisnowcomplete.Turnonthepowerandtestthexture.

CONNECTING THE WIRES

5.Haveanassistantsupportthexture’sweightwhilecompletingthewiring.Cutawaythe

excesswires.Threadthexture’swiresthroughthecanopyloopandnipple.Refertothe

wiringdiagramandattachthexture’swirestothepowersupplywiresfromthejunction

box.ConnectHottoHot,NeutraltoNeutral,andGroundtoGround.Twisttheendsof

thewirepairstogether,andthentwistonawireconnector.Makesurealltwistsarein

thesamedirection.Ifthereisnohousegroundwirecomingfromthejunctionbox,locate

groundscrew(E)onthemountingbracket/mountingstrapandwrapthexture’sground

wirearoundthegroundscrew.Useascrewdrivertotightenthetopofgroundscrew(E)

ontothewiresandintothemountingbracket/mountingstrap.Tuckthewiresintothe

junctionbox.

How to Identify the Fixture’s Wires

HotNeutralGround

Smooth

Ribbed

Bare Metal,

Green, or

Green Inner

Thread

Black

White

Black Inner

Thread

White Inner

Thread

House Wires

Fixture Wires

Hot

SEMI-FLUSH INSTALLATION
