IMPORTANT:
•ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.
•SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!
•USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!
CONNECTING THE WIRES
Have an assistant support the xture’s weight while completing the
wiring. Attach the xture’s wires to the power supply wires from the
junction box. Connect black to smooth/black/transparent (L) wire;
white to ribbed/white/transparent (N) wire; ground to ground (green or
copper). Twist the ends of the wire pairs together, and then twist on a
wire connector. Make sure all twists are in the same direction. If there is
no ground wire (green or copper) from the junction box, locate ground
screw on mounting strap (B) and wrap the xture’s ground wire around
the green ground screw. Use a screwdriver to secure ground screw
onto the mounting bracket/mounting strap. Tuck all wires neatly into
the junction box.
For Customer Service, contact
the place of purchase.
Assembly Instructions: 3306-FM (Orwell)
CLEANING TIPS
Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn o the light and wipe down
the xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture. Hand wash the glass with warm
waterand mild detergent. Dry with a lint-free or microber cloth.
PREPARING FOR INSTALLATION
Mounting screws (A) should be attached to mounting strap (B). Match
the threaded holes of mounting strap (B) to the spacing of the holes on
the junction box. Attach mounting strap (B) to the junction box using
mounting screws (D) and a screwdriver. Tighten securely. Mounting
screws (A) should protrude through the holes in mounting strap (B).
FINISHING THE INSTALLATION
Push canopy (F) up to the ceiling and tightly thread decorative nuts (H) onto the exposed threads of mounting screws (A).
Secure spider (I) to shade (L) with screws (K) and decorative caps (J). Carefully slide spider (I) over socket (G) and secure the shade in place with
socket ring (M).
Twist light bulbs (N - not provided) into sockets (G) in accordance with the xture’s specications. Do not exceed the maximum wattage.
Your installation is now complete. Turn on the power and test the xture.
GND
J
K
M
N
L
B
JUNCTION
BOX
D
A
E
C
F
H
G
I
Produktspezifikationen
| Marke: | Golden Lighting |
| Kategorie: | Beleuchtung |
| Modell: | Orwell 3306-FM |
