Assembly Instructions: 4309-SF/M3 (Mercer)

IMPORTANT:

•ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.

•SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!

•USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!

PREPARING FOR INSTALLATION

Remove all of the contents from the carton. See the important notes above. Remove

the old xture from the ceiling, including the old mounting strap. This xture may

be mounted as a pendant or ush mount. Choose how you would like to mount the

xture and follow the corresponding instructions.

1. From the parts bag remove the mounting strap assembly. Mounting strap (B) contains

holes. Two of mounting screws (A) should be attached to mounting strap (B). You may

need to tighten nuts (C) that hold these screws in place.

2. Place mounting strap (B) over the junction box so that mounting screws (A) are vertical,

and in alignment with the locations of the holes on canopy (G).

3. Secure mounting strap (B) to the junction box with mounting screws (D) and a

screwdriver. Tighten the screws securely.

4. Center rod (M) is on the wires, but not connected to lamp cluster (P). You may need to

twistcenterrod(M)tightlyontothethreadsofposts(V)and(T).Threadthexture’swires

through the center of swivel (H). Connect center post (L) to swivel (H). Tighten screw (I ) to

secure in place. Pull the wires until taut.

CLEANING TIPS

Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the

xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.

FINISHING THE INSTALLATION

6. Push canopy (G) up to the ceiling and tightly thread nuts (F) onto the exposed threads

of mounting screws (A).

7. Slide candle sleeves (U) over the sockets. Install light bulbs (not provided) in

accordancewiththexture’sspecications.Donotexceedthemaximumwattage.

8. Slide glass shade (O) followed by bottom cap (P) up over the socket cluster.

9.Threadspacer(Q)andbottomnial(R)ontothethreadsofbottompost(N)atthe

bottom of the lamp cluster to secure the glass in place.

Yourinstallationisnowcomplete.Turnonthepowerandtestthexture.

CONNECTING THE WIRES

5.Haveanassistantsupportthexture’sweightwhilecompletingthewiring.Cutawaythe

excesswires.Threadthexture’swiresthroughthecanopyloopandnipple.Refertothe

wiringdiagramandattachthexture’swirestothepowersupplywiresfromthejunction

box. Connect Hot to Hot, Neutral to Neutral, and Ground to Ground. Twist the ends of

the wire pairs together, and then twist on a wire connector. Make sure all twists are in

the same direction. If there is no house ground wire coming from the junction box, locate

groundscrew(E)onthemountingbracket/mountingstrapandwrapthexture’sground

wire around the ground screw. Use a screwdriver to tighten the top of ground screw (E)

onto the wires and into the mounting bracket/mounting strap. Tuck the wires into the

junction box.

How to Identify the Fixture’s Wires

HotNeutralGround

Smooth

Ribbed

Bare Metal,

Green, or

Green Inner

Thread

Black

White

Black Inner

Thread

White Inner

Thread

House Wires

Fixture Wires

Hot

SEMI-FLUSH INSTALLATION

V

U

M

O

P

Q

R

S

T

G

N

D

D

C

E

A

B

G

F

I

H

L

For Customer Service, please

contact the place of purchase.

Please note that the xture may be hung as a

pendant or a semi-ush. Please decide how

you would like the xture to be installed and

refer to the related instructions.
