Assembly Instructions: 2049-SF

IMPORTANT:

•ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.

•SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!

•USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!

PREPARING FOR INSTALLATION

Remove all of the contents from the carton. See the important

notes above. Shut off the power at the circuit breaker and

completelyremovetheoldxturefromtheceiling,includingthe

oldmountingstrap.

Fromthepartsbagremovethemountingstrapassembly.One

endofnipple(F)shouldbeattachedtomountingstrap(A)with

hexnutandwasher(C&D)inplace.Theotherendshouldhave

canopyloop(H)attached.Attachmountingstrap(A)tothe

junctionboxusingmountingscrews(B)andascrewdriver.Tighten

securely. Unscrew canopy loop collar (I) from canopy loop (H).

Passcanopy(G)overthemountedcanopylooptotesttheheight.

Approximatelyhalfofthecanopyloop’sexteriorthreadsshould

beexposed,andthecanopyloopcollarshouldtsnuglyonto

thecanopyloop.Removecanopy(G)andadjusttheheightof

nipple(F)andcanopyloop(H)untilthedesiredheightisreached.

Remove canopy (G) and canopy loop (H).

ASSEMBLING THE FIXTURE

Tiltglass(V)atanangleandslideitintoframe(R)tositonthetabs

on the inside of frame (R). You can slide it in from either the top or

thebottom.Placethebottomofframe(R)ontoaatsurface.Take

thexture’ssocketcluster(S)andcarefullyslidecandlesleeves(T)

over sockets (U).

Installbulbs(notprovided)inaccordancewiththexture’s

specications.Donotexceedthemaximumwattage.

Attachthexture’ssocketcluster(S)toframe(R)bythreading

deco nuts (Q) onto the posts at the top of frame (R).

Toploop(L)isonthexture’swires,butisnotattachedtothe

bodyofthexture.Passthexture’swiresthroughtoploop(L).

Pull the wires until taut and thread top loop (L) onto post (M) of

thexture’sbody.Bymeasuring,determinethecorrectnumberof

chainlinksneededforproperhangingheight.Ifnecessary,usea

pairofplierstoopenandremoveanyexcesschain(J).Attachone

ofchainconnectors(K)toeachendofchain(J).Twistthesidelock

to secure in place. Use one of chain connectors (K) to attach chain

(J)totoploop(L)andclosethechainconnector.Feedthexture’s

wiresupthroughthechain(everythreelinksorso),pullingthe

wiresuntiltaut.Usethefreechainconnector(K)toattachchain(J)

to canopy loop (H). Untwist canopy loop collar (I) to allow canopy

(G)tobeaddedtothechain.Feedthewiresupthroughthechain.

Allow canopy (G) to drop down onto the chain/wires.

CONNECTING THE WIRES

Haveanassistantsupportthexture’sweightwhilecompleting

thewiring.Cutawayanyexcesswireaddingatleast8to10

inchesofwiretothedesiredlength.Threadthexture’swires

throughcanopyloop(H)andnipple(F).Attachthexture’swires

tothepowersupplywiresfromthejunctionbox.Connectblack

toblack(orsmooth);whitetowhite(orribbed);groundtoground

(greenorcopper).Twisttheendsofthewirepairstogether,then

twist on a wire connector. Make sure all twists are in the same

direction.Ifthereisnogroundwire(greenorcopper)fromthe

junctionbox,locategroundscrew(E)onmountingstrap(A)and

wrapthexture’sgroundwirearoundthegreengroundscrew(E).

Useascrewdrivertosecuregroundscrew(E)ontothemounting

bracket.Tuckallwiresneatlyintothejunctionbox.

FINISHING THE INSTALLATION

Pushcanopy(G)uptotheceilingandslidecanopyloopcollar(I)

upbeneaththecanopy.Tightlythreadcanopyloopcollar(I)onto

canopy loop (H) to secure canopy (G) in place.

Hangcrystaldrops(P)ontohooks(N).

Your installation is now complete. Turn on the power and test the

xture.

CLEANING TIPS

Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the

xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.

For Customer Service, contact

the place of purchase to arrange

for replacement parts.

BLACK

(Hot)

WHITE

(Neutral)

GREEN

(Ground)

HOUSE WIRES

SMOOTH

(Or Black)

FIXTURE WIRES

RIBBED

(Or White)

BARE COPPER

(Or Green)

A

B

H

I

E

K

J

F

C

D

L

M

N

U

Q

P

S

T

R

G
