Assembly Instructions: (Mercer)4309-FM

IMPORTANT:

•ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.

•SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!

•USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!

PREPARING FOR INSTALLATION

Remove all of the contents from the carton. See the important notes above. Remove

theoldxturefromtheceiling,includingtheoldmountingstrap.

1.Fromthepartsbagremovethemountingstrapassembly.Mountingstrap(B)

containsthreadedholes.Twoofmountingscrews(A)shouldbeattachedtomounting

strap(B).Youmayneedtotightennuts(C)thatholdthesescrewsinplace.

2.Placemountingstrap(B)overthejunctionboxsothatmountingscrews(A)are

vertical,andinalignmentwiththelocationsoftheholesceilingpan(G).

3.Securemountingstrap(B)tothejunctionboxwithmountingscrews(D)anda

screwdriver.Tightenthescrewssecurely.

CLEANING TIPS

Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the

xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.

For Customer Service, contact

the place of purchase.

FINISHING THE INSTALLATION

5.Liftceilingpan(G)uptotheceilingandpositiontheceilingpansothat

mountingscrews(A)protrudethroughtheholesintheceilingpan.

6.Tightlythreadnuts(F)ontotheexposedthreadsofmountingscrews(A).

7.Installlightbulbs(notprovided)inaccordancewiththexture’s

specications.Donotexceedthemaximumwattage.

8.Raiseglassshade(J)upandovercoupler(H)whichisatthecenterofthe

ceilingpan.

9.Securetheglassinplacewithwasher(K),hexnut(L),bottomcap(M)and

bottomnial(N).Twisttightly.

Yourinstallationisnowcomplete.Turnonthepowerandtestthexture.

CONNECTING THE WIRES

4.Haveanassistantsupportthexture’sweightwhilecompleting

thewiring.Cutawaytheexcesswires.Threadthexture’swires

throughthecanopyloopandnipple.Refertothewiringdiagramand

attachthexture’swirestothepowersupplywiresfromthejunction

box.ConnectHottoHot,NeutraltoNeutral,andGroundtoGround.

Twisttheendsofthewirepairstogether,andthentwistonawire

connector. Make sure all twists are in the same direction. If there is

nohousegroundwirecomingfromthejunctionbox,locateground

screw(E)onthemountingbracket/mountingstrapandwrapthe

xture’sgroundwirearoundthegroundscrew.Useascrewdriver

totightenthetopofgroundscrew(E)ontothewiresandintothe

mountingbracket/mountingstrap.Tuckthewiresintothejunction

box.

How to Identify the Fixture’s Wires

HotNeutralGround

Smooth

Ribbed

Bare Metal,

Green, or

Green Inner

Thread

Black

White

Black Inner

Thread

White Inner

Thread

House Wires

Fixture Wires

Hot

GND
