Assembly Instructions: (Monroe)7041-6
IMPORTANT:
•ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.
•SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!
•USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!
House Wires
Fixture Wires
Hot
How to Identify the Fixture’s Wires
Smooth
Ribbed
Bare Metal,
Green, or
Green Inner
Thread
Black
White
Black Inner
Thread
White Inner
Thread
PREPARING FOR INSTALLATION
Remove all of the contents from the carton. See the important notes
above. Shut off the power at the circuit breaker and completely remove
theoldxturefromtheceiling,includingtheoldmountingstrap.
1.Takethemountingstrapassemblyfromthepartsbag.Oneendof
nipple(F)shouldbeattachedtomountingstrap(A)withwasherandhex
nut (C and D) in place. Canopy loop (H) is attached to the other. Securely
attachmountingstrap(A)tothejunctionboxusingmountingscrews(B)
and a screwdriver.
2. Unscrew canopy loop collar (I) from canopy loop (H). Pass canopy (G)
overthemountedcanopylooptotesttheheight.Approximatelyhalfof
thecanopyloop’sexteriorthreadsshouldbeexposed,andthecanopy
loopcollarshouldtsnuglyontothecanopyloop.Removecanopy(G)
andadjusttheheightofnipple(F)andcanopyloop(H)untilthedesired
heightisreached.
3.Oneofconnectorrods(N)hasthexture’swiresinside.Hook
connectorrods(N)totheframeatloops(Q)andthenpullthexture
wires until taut. Attach the top of connector rods (N) to loops (R). Top
loop(L)isonthexturewires,butnotattachedtothebodyofthexture.
Passthexturewiresthroughtoploop(L).Pullthewiresuntiltautand
threadtoploop(L)ontothexturebody.
4.Bymeasuring,determinethecorrectnumberofchainlinksneeded
forproperhangingheight.Ifnecessary,useapairofplierstoopenand
removeanyexcesschain.Attachonechainconnector(K)toeachendof
chain (J). Use one of chain connectors (K) to attach chain (J) to top loop
(L)andclosethechainconnector.Feedthexturewiresupthroughthe
chain(everythreelinksorso),pullingthewiresuntiltaut.Slidecanopy
loop collar (H) and canopy (G) onto the chain/wire. Use the free chain
connector (K) to attach chain (J) to canopy loop (H).
FINISHING THE INSTALLATION
6.Raisecanopy(G)uptotheceilingandslidecanopyloopcollar(I)upbeneaththecanopy.Tightlythreadcanopyloopcollar(I)onto
canopy loop (H) to secure canopy (G) in place.
7.Slideglassshades(P)oversockets(M)andsecureinplacewithsocketcovers(O).
8.
Installlightbulbs(notprovided)inaccordancewiththexture’sspecications.Donotexceedthemaximumrecommended
wattage.
Yourinstallationiscomplete.Turnonthepowerandtestthexture.
For Customer Service, please
contact the place of purchase.
CLEANING TIPS
Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the
xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.
CONNECTING THE WIRES
5.Haveanassistantsupportthextureweightwhilecompletingthewiring.Cutawayexcesswire.Attachthexture’swirestothe
powersupplywiresfromthejunctionbox.Connectblacktoblack(orsmooth);whitetowhite(orribbed);groundtoground(green
orcopper).Twisttheendsofthewirepairstogether,thentwistonawireconnector.Makesurealltwistsareinthesamedirection.If
thereisnogroundwire(greenorcopper)fromthejunctionbox,locategroundscrew(E)onmountingstrap(B)andwrapthexture’s
groundwirearoundthegreengroundscrew(E).Useascrewdrivertosecuregroundscrew(E)ontothemountingbracket.Tuckall
wiresneatlyintothejunctionbox.
