IMPORTANT:
•ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.
•SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!
•USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!
CONNECTING THE WIRES
Have an assistant support the xture’s weight while completing the wiring. Cut away excess
wire. Attach the xture’s wires to the power supply wires from the junction box. Connect black
to smooth/black/transparent (L) wire; white to ribbed/white/transparent (N) wire; ground to
ground (green or copper). Twist the ends of the wire pairs together, and then twist on a wire
connector. Make sure all twists are in the same direction. If there is no ground wire (green
or copper) from the junction box, locate ground screw on mounting strap (A) and wrap the
xture’s ground wire around the green ground screw. Use a screwdriver to secure ground
screw onto the mounting bracket/mounting strap. Tuck all wires neatly into the junction box.
For Customer Service, contact
the place of purchase.
Assembly Instructions: 3167-M1L (Colson)
CLEANING TIPS
Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn o the light and wipe down the
xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.
PREPARING FOR INSTALLATION
Carefully remove all of the contents from the carton. See the important notes above. Shut o the
power at the circuit breaker and completely remove the old xture from the ceiling, including the old
mounting strap.
From the parts bag remove the mounting strap assembly. Mounting strap (A) contains threaded holes.
Two of mounting screws (C) should be attached to mounting strap (A). You may need to tighten the
nuts that hold these screws in place. Place mounting strap (A) over the junction box so that mounting
screws (C) are vertical, and in alignment with the hole locations on the xture’s canopy (D). Secure
mounting strap (A) to the junction box with mounting screws (B) and a screwdriver. Tighten the screws
securely.
FINISHING THE INSTALLATION
Push canopy (D) up to the ceiling and tightly thread nuts (E) onto the exposed threads of mounting screws (C).
Install the bulbs (J- not included) into sockets (K) in accordance with the xture’s specications. Do not exceed the maximum wattage
Your installation is now complete. Turn on the power and test the xture.
ASSEMBLING THE FIXTURE
(Fig2) Shade (L) may be included with the xture. If the
shade is included, please check to see which side (top
or bottom has the acrylic clip (M) attached. Place shade
(L) over the spherical arms (L) of the xture.
For adjusting the height of xture, this xture contains:
Three 12” rods (G) and one 6” rod (F). Each rod can be
connected to another by twisting the thread end of one
into the opposite end of another. Each rod may also be
used to alone to connect the xture body to the swivel
(H2) on canopy (D). By measuring, decide the desired
overall height of your xture and determine how many
rods are needed to achieve the desired height. Push the
xture’s wires through each rod. Thread the bottom rod
onto post (H) of the xture’s body. Pull the wires until
taut and then connect the rods together as described
above. If the Rod (F) can not be threaded into swivel
(H2), please use the Hexagon wrench (H3) to loosen
screw (H4).
G1
G3
A
B
C
G2
K
L
J
H
I
F
D
E
H2
H4
H3
K
L M
Fig 2
