IMPORTANT:
•ALLINSTALLATIONWORKSHOULDBEDONEBYACCREDITEDPROFESSIONAL.
•SHUTOFFPOWERSUPPLYATFUSEORCIRCUITBREAKER!
•USEONLYTHESPECIFIEDBULBS.DONOTEXCEEDTHEMAXIMUMWATTAGE!
A:ssemblyInstructions(Zoey)6956-S/L
CLEANING TIPS
Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the
xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.
PREPARING FOR INSTALLATION
the power at the circuit breaker and completely remove the old xture from the ceiling,
including the old mounting strap.
1.Takethemountingstrapassemblyfromthepartsbag.Mountingstrap(B)containsseveral
threadedholes.Twoofmountingscrews(A)shouldbeattachedtomountingstrap(B).You
mayneedtotightennuts(C)thatholdthesescrewsinplace.Ifthescrewsarenotattached,
pleaseholdcanopy(F)uptomountingstrap(B).Lineuptheholesincanopy(F)withtheholes
inmountingstrap(B)andinsertmountingscrews(A)intomountingstrap(B)sothatmounting
screws(A)protrudethroughtheholesincanopy(F).Mountingscrews(A)arelong,sopleasetest
thecanopyagainstthemountingstraptoseehowfaryoushouldinsertthescrews.Removethe
canopyandthentightennuts(C)ontomountingscrews(A)toholdthescrewsinplace.
2.Placemountingstrap(B)overthejunctionboxandsecureinplacewithmountingscrews(D).
Tightenthescrewssecurelywithascrewdriver.
ASSEMBLING THE FIXTURE
3.Measuretodeterminethecorrectnumberofrods(Kand/orL)neededforproperhanging
height.
4.Threadthexture’swiresthroughrods(Kand/orL)beforethreadingtherodstogetherandthen
ontopost(M).Tolengthenthexture,addadditionalrods.Ifadditionalrodsareneeded,contact
theplaceofpurchasetoorder.Toshortenthexture,slideanyexcessrodsoffthexture’swires
todiscard.Pullthewiresthroughrodloop(I)andthreadrodloop(I)intothetoprod(KorL).Open
chainconnector(G)andhookthechainconnectortorodloop(I)andcanopyloop(P).Closechain
connector(G).Passthexture’swiresthroughthechainconnector,canopyloop,andcanopy(F).
Keepatleast8to10inchesofwiremorethanthedesiredlengthandtrimtheexcesswires.
For Customer Service, please
contact the place of purchase.
FINISHING THE INSTALLATION
6.Pushcanopy(F)uptotheceilingandtightlythreadnuts(H)ontothethreadsofmountingscrews(A).
7.Pushglassshade(O)upoverthethreadsofsocket(N).Securetheglassinplacebytwistingsocketcover(J)ontothesocket.
8.Installalightbulb(notprovided)basedonthexture’sspecications.Donotexceedthemaximumwattage.
Yourinstallationisnowcomplete.Turnonthepowerandtestthexture.
CONNECTING THE WIRES
5.Haveanassistantsupportthexture’sweightwhilecompletingthewiring.Refertothewiring
diagramandattachthexture’swirestothepowersupplywiresfromthejunctionbox.Connect
HottoHot(blackorsmooth),NeutraltoNeutral(whiteorribbed),andGroundtoGround(greenor
copper).Twisttheendsofthewirepairstogether,andthentwistonawireconnector.Makesure
alltwistsareinthesamedirection.Ifthereisnohousegroundwirecomingfromthejunctionbox,
locategroundscrew(E)onthemountingbracket/mountingstrapandwrapthexture’sground
wirearoundthegroundscrew.Useascrewdrivertotightenthetopofgroundscrew(E)ontothe
wiresandintothemountingbracket/mountingstrap.Tuckthewiresintothejunctionbox.
House Wires
Fixture Wires
Hot
How to Identify the Fixture’s Wires
HotNeutralGround
Smooth
Ribbed
Bare Metal,
Green, or
Green Inner
Thread
Black
White
Black Inner
Thread
White Inner
Thread
A
B
C
D
E
F
G
H
I
J
K
L
M
N
JUNCTION
BOX
O
