Assembly Instructions: 7151-SF (Bellare)

IMPORTANT:

•ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.

•SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!

•USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!

PREPARING FOR INSTALLATION

Please note that this xture can be installed as a semi-ush or as a

pendant and includes two canopies (G1 and G2). Please decide how you

wouldliketoinstallthextureandchoosetheappropriatecanopy.Canopy

(G1)hastwosmallholesandoneholeinthecenter.Thiscanopyisusedfor

semi-ushinstallation.Forsemi-ushinstallation,pleasefollowtheinstructions

below.Canopy(G2)hasalargeholeinthecenter.Thiscanopyisusedfor

pendantinstallation.Forpendantinstallation,pleaseipthepageandfollow

the instructions.

Carefullyremoveallofthecontentsfromthecarton.Seetheimportantnotes

above.Shutoffthepoweratthecircuitbreakerandcompletelyremovetheold

xturefromtheceiling,includingtheoldMountingplate.

Fromthepartsbagremovethemountingplateassembly.mountingplate(B)

containsseveralpairsofthreadedholes.Findthepairofholesthatmatches

thespacingoftheholesonthejunctionboxandyourxturebackplate.Two

ofmountingscrews(A)shouldbeattachedtomountingplate(B).Youmay

needtotightenthenutsthatholdthesescrewsinplace.Pullthehousewires

throughthecenterofmountingplate(B).Placemountingplate(B)overthe

junctionboxsothatmountingscrews(A)arevertical,andinalignmentwiththe

holelocationsonthexture’scanopy(G1).Securemountingplate(B)tothe

junctionboxwithmountingscrews(D)andascrewdriver.Tightenthescrews

securely.

Takexturebody(Q)outofthebox.Screwnipple(O)intopost(P).Securein

placewithhexnut(U).Slidecover(N)andspacer(M)overnipple(O).Slide

canopy(G1)overtheexposedthreadsofnipple(O).Thenslideongasket(J),

andspacer(I).Twistonhexnut(H)tolockthepiecestogether.

CONNECTING THE WIRES

Attachthepowersupplywiresfromthejunctionboxtothexture’swires.

Connectblacktoblack(orsmooth);whitetowhite(orribbed);groundtoground

(greenorcopper).Twisttheendsofthewirepairstogether,andthentwiston

awireconnector.Makesurealltwistsareinthesamedirection.Ifthereisno

groundwire(greenorcopper)fromthejunctionbox,locategroundscrewon

mountingplate(B)andwrapthexture’sgroundwirearoundthegreenground

screw.UseascrewdrivertosecurethegroundscrewontotheMountingplate.

Tuckallwiresneatlyintothejunctionbox.

FINISHING THE INSTALLATION

Raisecanopy(G1)tomountingplate(B)andpositionmountingscrews(A)

thattheyprotrudethroughtheopeningsofcanopy(G1).Securecanopy(G1)in

placewithdecorativenuts(F).

Slidecandlesleeves(S)oversockets(T).Installlightbulbs(R-notprovided)in

accordancewiththexture’sspecications.Donotexceedtherecommended

wattage.

Yourinstallationisnowcomplete.Turnonthepowerandtestthexture.

BLACK

(Hot)

WHITE

(Neutral)

GREEN

(Ground)

HOUSE WIRES

SMOOTH

(Or Black)

FIXTURE WIRES

RIBBED

(Or White)

BARE COPPER

(Or Green)

For Customer Service, contact the

place of purchase to arrange for

replacement parts.

SEMI-FLUSH INSTALLATION

CLEANING TIPS

Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the

xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.
