Seite 1/13
1. INTRODUCTION
Smart DIN Thermostat. Heatit DIN Smart Thermostat is an
electronic multifunction thermostat designed for electrical
heating. The thermostat can be controlled through Z-Wave
®
via a Z-Wave gateway. It can also be controlled using Modbus
RS-485 and the buttons on the front of the thermostat. The
thermostat features a user-friendly interface.
The Heatit DIN Smart Thermostat is a versatile solution for
both residential and industrial use. It functions as a standard
floor heating thermostat, oering simple temperature control
with three modes: Heat, Cool, and Eco. With the Heatit DIN
Smart Thermostat, you get precise temperature control for a
wide range of applications.
The thermostat clicks easily onto a standard DIN rail and can
be installed in the main switchboard. The thermostat has
connection for two external temperature sensors.
The Heatit DIN Smart Thermostat features active power
metering, providing real-time information about your power
consumption. It also allows you to manually set the power
metering value when connected to a contactor.
The device is equipped with ZeroX™ technology, which
ensures the relay switches at 0V when turning on and o. This
technology significantly extends the thermostat’s lifespan.
The Heatit DIN Smart Thermostat has been developed for
central control systems, with all features easily accessible via
MODBUS RS-485.
2. ELECTRICAL LOAD COMPATIBILITY
The thermostat is designed specifically for resistive loads.
When controlling large resistive, capacitive, or inductive loads,
it is essential to use an appropriate contactor to protect the
thermostat from excessive load to ensure safe operation.
The thermostat can withstand a resistive load of up to
16A/3600W at 230VAC. For loads above 13A, we recommend
using a contactor.
3. STATEMENT REGARDING PRODUCTS FROM MULTIPLE
MANUFACTURERS
Please read this before installation
This device may be used with all devices certified with the
Z-Wave
®
Plus certificate and should be compatible with
such devices produced by any manufacturer. Every primary
controller/gateway is dierent depending on the manufacturer,
their target audience and intended use/application. Please
review the functionalities implemented by the primary
controller/gateway you intend to use with our Z-Wave Plus
certified device to ensure that it provides the necessary
controls to take full advantage of our product’s capabilities.
PRODUCT
DOCUMENTS
HEATIT
DIN SMART
THERMOSTAT
Z-Wave Installers manual
Firmware version Document version
FW 1.0 Ver-B
Article no. Document date
54 304 59 01.10.2025
Org. doc. date 01.10.2025
TABLE OF CONTENTS
1. Introduction
2. Electrical Load
Compatibility
3. Statement regarding
products from multiple
manufacturers
4. Behavior within the
Z-Wave network
5. Installation Disclaimer
6. Quick Start
7. Connections
8. Installation
9. Thermostat controls
10. Local settings menu
11. Display Menu structure
12. Startup
13. Add/Remove
14. QR-Code Placement
15. Factory Reset
16. Thermostat mode
17. Standby and main screen
18. Temperature shown in
display
19. Choice of sensor/
Operating mode
20. Selecting sensor value
21. MIN/MAX temperatures
22. Calibration
23. Brightness
24. Principles of regulation
25. Open window detection
26. Size of load
27. KWh value in menu
28. Display icons
29. Display on/o
30. Child lock
31. Associations
32. Association Groups
33. Modbus
34. Configuration Parameters
35. Firmware update - OTA
36. Command Classes
37. Supported Command
Classes
38. Controlled command
classes
39. Security
40. Node Information Frame
41. Dimensions
42. Safety features
43. Error codes
44. CHART - Display Menu
Structure
Product info
Heatit DIN Smart Thermostat
54 304 59
