Seite 1/11
Instruction
Manual
Instruction
Manual
ENGLISH
www.kleintools.com
For Professionals...Since 1857
®
CL3100
VOLTS
:
1.3~750VAC
AMPS:
0.9~200 AAC
OHMS:
0
~
40MΩ
Cont
inuity
2.1~1000VDC
-1.8~-1000VDC
MAX/MIN
CL3100
V
AT
0 10 20 4030
Apo
600V
200A
CAT IV
ENGLISH
CL3100
Instruction Manual
GENERAL SPECIFICATIONS
The Klein Tools CL3100 is an auto-function selecting hook meter.
It measures AC / DC voltage, AC current, and resistance. It can also test
continuity.
• Operating Altitude: 2000 meters
• Relative Humidity: 75% max
• Operating Temperature: 0°C / 32°F to 40°C / 104°F
• Storage Temperature: -10°C / 0°F to 50°C / 122°F
• Accuracy Temperature: 18°C / 64°F to 28°C / 82°F
• Temperature Coefficient: 0.1*(specified accuracy) / °C
• Sampling Frequency: 2.5 samples per second
• Jaw Size: 0.5"
• Dimensions: 10.25" x 2.5" x 1.5"
• Weight: 8.6oz.
• Calibration: Accurate for one year
• CAT Rating: CAT III 1000V, CAT IV 600V
• Accuracy: ± (% of reading + # of least significant digits)
WARNINGS
To ensure safe operation and service of the tester, follow these instructions.
Failure to observe these warnings can result in severe injury or death.
• Before each use, verify meter operation by measuring
a known voltage or current.
• Never use the meter on a circuit with voltages that exceed the category based
rating of this meter.
• Do not use the meter during electrical storms, or in wet weather.
• Do not use the meter or test leads if they appear to be damaged.
• Ensure meter leads are fully seated, and keep fingers away from
the metal probe contacts when making measurements.
• Do not open the meter to replace batteries while the probes
are connected.
• Use caution when working with voltages above 60V DC,
or 25V AC RMS. Such voltages pose a shock hazard.
• To avoid false readings that can lead to electrical shock,
replace batteries if a low battery indicator appears.
• Unless measuring voltage or current, shut off and lock out
power before measuring resistance or capacitance.
• Always adhere to local and national safety codes. Use individual protective
equipment to prevent shock and arc blast injury where hazardous live
conductors are exposed.
SYMBOLS
~
AC Alternating Current Warning or Caution
DC/AC Voltage or Current Double Insulated Class II
DC Direct Current Ground
Safe for disconnect
from live conductors
AC Source
• BACKLIGHT
• WORKLIGHT
• MAX / MIN
• AUTO FUNCTION
SELECT
• 3-3/4 DIGIT
3999 COUNT LCD
ENGLISH
VOLTS
:
1.3~750VAC
AMPS:
0.9~200 AAC
OHMS:
0
~
40MΩ
Cont
inuity
2.1~1000VDC
-1.8~-1000VDC
MAX/MIN
CL3100
V
AT
0 10 20 4030
Apo
600V
200A
CAT IV
B
C
D
E
A
F
MAX/MIN
CL3100
V
AT
0 10 20 4030
Apro
VOLTS
:
1.3~750VAC
AMPS:
0.9~200 AAC
OHMS:
0
~
40MΩ
Cont
inuity
2.1~1000VDC
-1.8~-1000VDC
Where to Measure
A. Measure Voltage, Resistance, and Continuity here
•
Use leads of proper safety rating only (CAT III / CAT IV).
•
Do not attempt to measure more than 1000V DC or 750V AC.
•
Do not attempt to measure current with leads.
B. Measure Current here
•
Measure up to 200A AC.
• Measure when display shows AUTO.
How to Select a Function or Feature
C. Use to turn instrument ON / OFF, or select MAX / MIN.
• Press button for 2 seconds to power on or off.
• Press repeatedly to switch between maximum and minimum.
• Press button for 2 seconds to return to live reading from MAX/
MIN mode.
D. Access Resistance, Continuity, and Backlight functions here.
• Press repeatedly to cycle through AUTO (V / A), resistance,
and continuity modes.
• Press for 2 seconds to enable/disable backlight and worklight.
Other Things to Note:
E. Magnet and Battery Replacement are on back.
• When
indicator is displayed on the LCD,
batteries must be replaced.
• Turn off device and disconnect leads.
• Remove the back screw and replace 2 x AAA batteries.
• Attach magnet to metal surfaces for hands-free use.
F.
Device features Auto Power-Off (Apo)
• After 29 minutes non-use, the instrument will beep 3 times.
• After 1 more minute, the instrument will beep once and power
itself off to conserve battery power.
• Holding VA /
Ω button while turning on disables Auto Power-Off.
1. Voltage:
<
1000 V DC or 750 V AC
FUNCTION INSTRUCTIONS
FEATURE DETAILS
