PRODUCT DATA

OSCxx-RMW

Multi-Technology Ceiling

Occupancy Sensor with Isolated Relay

BASIC OPERATION

Occupancy sensors have two tasks: 1) Keeping the

lights ON while the room is occupied, and 2) Saving

energy by keeping the lights OFF while the room is

unoccupied.

The Leviton OSCxx-RMW sensors combine

the benefits of both Passive Infrared (PIR) and

Ultrasonic (U/S) technologies for unrivaled

performance and reliability. Additionally, the sensor

is designed with an isolated relay contact; which

enables the sensor to interface with other systems

(example: BAS, HVAC or any dry-contact capable

device or system).

APPLICATIONS

• Cafeterias • Classrooms

• Computer rooms • Conference rooms

• Day care centers • Stairwells

• Workspaces • Executive, open,

• Restrooms and private offices

• Offices with cubicles

FEATURES

• Multi-Technology: By using both PIR and U/S

signals, the sensor minimizes false triggering for

high reliability

• Isolated Relay: Supports HVAC or other Class 2 low

voltage signals

• Supports both 24VAC/VDC power supplies

• Wide Coverage: Units from 500 to 2000 sq. ft.

available

• Self-Adjusting: Internal microprocessor

con tin u al ly analyzes, evaluates and adjusts

the sensitivity and time delay. Performance is

kept at a maximum and user complaints are

eliminated.

• Custom white color matched for most common

daylight harvesting architecture

• Uses OSPxx Series Power Pack: uses Class 2, 24

volt wiring, three wire connection (low voltage).

Multiple sensors can control single or multiple

power packs

•

Additional mid-range lens assembly included for

applications with mounting heights between

12’-20’

• Fast, simple in stal la tion: easy ceiling mount,

twist-lock sensor attachment for 360° rotation

and flexibility

• Small motion sensitivity: The ultrasonic

tech nol o gy provides excellent small motion

sensitivity

• Timer setting feature: automatic—30sec–30min.

Test mode—4sec with auto exit programming

• Non-volatile memory: learned and adjusted settings

saved in protected memory are not lost during

power outages

• Walk-through: provides increased energy

savings by decreasing the time delay to 2.5min

when someone momentarily walks through the

monitored space

• Ultrasonic components: one or two U/S

transducers and one or two narrow bandwidth

receivers each 16mm in diameter. Frequency—

Crystal controlled to ±.005%.

• Device: rug ged, high-im pact, in jec tion molded

plas tic, white. Col or coded leads 7” (17.78 cm)

Leviton Manufacturing Co., Inc. Global Headquarters

201 North Service Road, Melville, NY 11747-3138 tech line 800-824-3005 fax 800-832-9538

Produktspezifikationen

Marke:	Leviton
Kategorie:	Bewegungsmelder
Modell:	OSC20-RMW
Breite:	106.68 mm
Tiefe:	39.9 mm
Produktfarbe:	Weiß
Übertragungstechnik:	Kabelgebunden
Energiequelle:	AC
Betriebstemperatur:	0 - 40 °C
Relative Luftfeuchtigkeit in Betrieb:	0 - 95 %
Menge pro Packung:	1 Stück(e)
Eingangsspannung:	24 V
Sensor-Typ:	Passiver Infrarot-Sensor (PIR)
Gewährleistungsfrist:	5 Jahr(e)
Einstellzeit:	30 s
