9SC & 10SC SERIES

OWNER'S MANUAL

English

EN

This submersible sewage pump is for use in basins or

lift stations and is suitable for pumping effluent gray

water or wastewater with up to 2" (51 mm) spherical

semi-solids. Do not use the pump in applications

where any other debris (gravel, sand, floating debris,

etc.), abrasives, or corrosives are present.

The pump motor is equipped with an automatic reset-

ting thermal protector and may restart unexpectedly.

Protector tripping is an indication of motor overload-

ing/overheating, which can be caused by application

issues such as an obstructed pump impeller, switch

stuck in the ON position, pump running dry, pump air-

locked, pump short cycling, excessively high or low

voltage supply, or possibly a pump, motor, bearings, or seal that have reached the end of their useful life.

This product is covered by a Limited Warranty for a period of 3 years from the date of original purchase by

the consumer. For complete warranty information, refer to www.littlegiant.com

.

Specifications

ModelHPVoltsHz

Amps

Watts

Maximum Water

Temperature

FLAStart

9SC4/10

11560

8.0

18.5

870

140 °F

(60 °C)

10SC (2” Discharge)

1/2

11.01225

23050/605.5/5.513/13

991/1214

10SC (3” Discharge)

1004/1228

1156011.518.51270

Model

Gallons (Liters) per Minute, at HeightShut Off

5 ft (1.5 m)10 ft (3 m)15 ft (4.5 m)20 ft (6.1 m)Feet (Meters)PSI (Bar)

9SC100 (379)80 (303)60 (227)-20 (6.1)8.7 (0.6)

10SC (2” Discharge)120 (454)100 (379)80 (303)42 (159)25 (7.6)10.9 (0.7)

10SC (3” Discharge)130 (492)110 (416)85 (322)50 (189)25 (7.6)10.8 (0.7)

Model Switch TypeON LevelOFF Level

9SC-CIA-SFSIntegral Snap-Action Float10 - 13” (25 - 33 cm)5 - 8” (13 - 20 cm)

9SC-CIA-RF

Piggyback Mechanical Float16 - 19” (41 - 48 cm)9 - 11” (23 - 28 cm)

10SC-CIA-RF

10SC-CIA-SFSIntegral Snap-Action Float11 - 14” (28 - 36 cm)6 - 9” (15 - 23 cm)
