INSTALLATION INSTRUCTIONS
107-UN02
Attention!Let the vehicle sit with the key
out of the ignition for a few minutes before
removing the factory radio. When testing the
equipment is connected before cycling the
key to ignition.
Patent Pending
KIT FEATURES
KIT COMPONENTS
• A) Assembly mount • B) Display housing • C) Display trim ring • D) Display brackets • E) Display brackets (5-degree angle)
• F) (4) #8 x 1/2” Phillips screws • G) (4) 4mm Allen head screws
ABCDE
G
Floating Mount Kit Pioneer 6.8-inch
TOOLS REQUIRED
• Phillips screwdriver
• 4mm Allen head screwdriver
TABLE OF CONTENTS
Preface ....................................................................2
Kit Assembly ..........................................................3
WIRING & ANTENNA CONNECTIONS
(sold separately)
RGB Extension Cable: CD-RGB150E
(not sold by Metra)
F
The 107-UN02 is a universal mount
designed to “float” the Pioneer
6.8-inch screen in front of a vehicle’s
original radio location using a series
of brackets that provide the ability to
easily mount the radio’s chassis into
the radio/pocket location of more than
250 existing Metra Double-DIN kits for
1990 to current vehicle applications.
Designed specifically for Pioneer
modular 6.8” radios like the
DMH-C2550NEX and DMH-C2500NEX.
A complete housing encases
the Pioneer 6.8-inch screen
Patent-pending design
