Metra. The World’s Best Kits.
®
MetraOnline.com © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION REV. 2/13/24 INST95-7641B
I N S TA L L AT I O N I N S T R U C T I O N S
95-7641B
Attention! With the key out of the ignition,
disconnect the negative battery terminal
before installing this product. Ensure that all
installation connections are secure before
cycling the ignition to test this product.
KIT FEATURES
• ISO DDIN radio provision
• ISO DIN radio provision with pocket sold separately
• Painted scratch resistant matte black
• Most full size DDIN radios will require a small cut in the sub dash for
clearance. Shallow chassis radios should not require any cutting.
KIT COMPONENTS
• A) Radio trim panel • B) Radio brackets • C) Panel clips (4) • D) #8 x 3/8” Phillips screws (4)
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
TABLE OF CONTENTS
Dash Disassembly.............................................. 2-4
Kit Preparation 5 .......................................................
Kit Assembly ..........................................................6
WIRING & ANTENNA CONNECTIONS
(sold separately)
Wiring Harness: 70-7552
Antenna Adapter: 40-EU10
Visit
axxessinterfaces.com for more audio/video
and steering wheel control interface options.
A B C D
Nissan Frontier 2022-Up
Visit for more detailed information about the product and up-to-date vehicle MetraOnline.com
specific applications
386.257.1187
|
MetraOnline.com
2
1. Remove the rubber pad from the pocket
above the radio then remove (2) Phillips
screws under pad. (Figure A)
2. Unclip and remove the panel from
inside the pocket. (Figure B)
3. Remove the (2) Phillips screws from
the top of the radio brackets inside the
pocket area. (Figure C)
Continued on the next page
(Figure A) (Figure B) (Figure C)
DASH DISASSEMBLY
REV. 2/13/2024 INST95-7641B
3
(Figure E) (Figure F) (Figure D)
DASH DISASSEMBLY (CONT.)
4. Unclip and remove the switch panel
below the A/C controls. (Figure D)
5. Remove (2) Phillips screws exposed
behind switch panel on bottom of A/C
controls. (Figure E)
6. Unclip and remove the A/C control
panel. (Figure F)
Continued on the next page
