Bayco Products, Inc. • 640 South Sanden Blvd. • Wylie, TX 75098 • 1-800-233-2155 • 1-469-326-9400 • www.nightstick.com

INS-XPP5412G-15

05-07-2018

Instruction Manual

XPP-5412G

Please read these instructions before using your Nightstick XPP-5412G

Intrinsically Safe Penlight. They include important safety information and

operating instructions.

THE XPP-5410G IS APPROVED FOR USE

Nightstick 5412 Penlight

CLASS I DIV 1 GRPS A-D T3

CLASS II & III DIV1 GRPS E-G T135C

CLASS I ZONE 0 AEx ia IIC T3 Ga

CLASS I ZONE 0 Ex ia IIC T3 Ga

Ex ia op is I Ma

Ex ia op is IIC T3 Ga

Intertek ITS 13 ATEX27839X

IECEx ITS 14.0036X

-20ºC ≤ Tamb ≤ +40ºC

1.5V/Cell AAAA Alkaline

0359

ID 4001184

INTRINSICALLY SAFE

SECURITE INTRINSEQUE

I M 1 Ex ia op is I Ma

II 1 G Ex ia op is IIC T3 Ga

Conforms to:

ANSI/UL STD 913, ANSI/UL

60079-0, ANSI/UL 60079-11

ANSI/ISA 60079-26

Certified to:

CAN/CSA STD C22.2 No 157

CAN/CSA STD C22.2 No 60079-0

CAN/CSA STD C22.2 No 60079-11

CSA STD C22.2 No 25

WARNINGS - INTRINSICALLY SAFE

yWarning: Use only the approved non-rechargeable batteries listed below.

yWarning: Do NOT attempt to use rechargeable AAAA batteries with this

light.

yWarning: To prevent ignition of a hazardous atmosphere, do not open

the lens bezel in the hazardous environment. This task must ONLY be

performed in an area known to be non-hazardous.

yWarning: When exchanging batteries, use only DURACELL MX2500 OR

ENERGIZER E96 BATTERIES.

yWarning: To prevent ignition of a hazardous atmosphere, the AAAA

batteries must only be exchanged in an area known to be non-hazardous.

yWarning: To reduce the risk of explosion, do not mix new non-rechargeable

batteries with used non-rechargeable batteries, or mix non-rechargeable

batteries from different manufacturers.

yWarning: Substitution of components may impair intrinsic safety.

SPECIAL INSTRUCTIONS FOR INTRINSIC SAFETY

yFor personal safety, always conrm the rating of any known hazardous or

potentially hazardous location where the light is to be used.

BATTERY INSTALLATION

WARNING: In order to maintain the XPP-5412G’s Intrinsically Safe

rating, the only AAAA batteries certied for use with this light are the

DURACELL MX2500 OR ENERGIZER E96 BATTERIES.

yDo not attempt to use any other brand or model of AAAA batteries with

this light.

yDo not attempt to use any type of rechargeable AAAA batteries with this

light.

Warning: To prevent ignition of a hazardous atmosphere, do not remove

the lens bezel in the hazardous environment. This task must ONLY be

done in an area known to be non-hazardous.

yLoosen the locking screw located on the side of the lens bezel. NOTE:

Do NOT attempt to completely remove the locking screw. Doing so is not

necessary and may damage the threads. The screw simply needs to be

loosened enough to allow the lens bezel to unscrew.

yUnscrew the lens bezel from the housing in a counter-clockwise direction.

yUsing 3 – AAAA DURACELL MX2500 OR ENERGIZER E96 BATTERIES

(make sure all three batteries are of the same type), install the batteries in

the light paying close attention to make sure that the positive end of the

batteries point toward the bezel end of the light.

yReplace the lens bezel by screwing it onto the housing in a clockwise

direction.

yTighten locking screw. CAUTION: Do NOT over-tighten. Doing so may

damage the threads and impact the light’s Intrinsic Safety.

OPERATION

THE XPP-5412G HAS TWO SEPARATE LIGHTING MODES:

MOMENTARY FLASHLIGHT MODE

Lightly press the tail switch for momentary operation. Release the switch

to turn the light off.

CONSTANT-ON FLASHLIGHT MODE

Press the tail switch until it clicks and then release for constant-on mode.

Press and release the tail switch again to turn the light off.

WARRANTY

LIMITED LIFETIME WARRANTY

Bayco Products, Inc. warrants this product to be free from defects in

workmanship and materials for the original purchaser’s lifetime. The Limited

Lifetime Warranty includes the LEDs, housing and lenses. Rechargeable

batteries, chargers, switches, electronics and included accessories are

warranted for a period of two years with proof of purchase. Normal wear and

failures which are caused by accidents, misuse, abuse, faulty installation and

lightning damage are excluded.

We will repair or replace this product should we determine it to be

defective. This is the only warranty, expressed or implied, including any

warranty of merchantability or tness for a particular purpose.

For a complete copy of the warranty, go to www.nightstick.com/nightstick-

product-support/warranties. Retain your receipt for proof of purchase.
