Bayco Products, Inc. • 640 South Sanden Blvd. • Wylie, TX 75098 • USA • 1-800-233-2155 • 1-469-326-9400 • www.nightstick.com

INS-XPR-5561GC-DL-21

02-08-2021

Instruction Manual

XPR-5561GC

THE XPR-5561GC IS APPROVED FOR USE

CLASS I DIV 1 GRPS A-D T4

CLASS II & III DIV1 GRPS E-G T135°C

CLASS I ZONE 0 AEx ia IIC T4 Ga

CLASS I ZONE 0 Ex ia IIC T4 Ga

Ex ia I Ma

Ex ia IIC T4 Ga

DEMKO 17 ATEX 1826

IECEx UL 17.0005

-20ºC ≤ Tamb ≤ +40ºC

3.7V/Cell Li-ion

Um: 10V

2575

E 467756

INTRINSICALLY SAFE

SECURITE INTRINSEQUE

I M1 Ex ia I Ma

II 1 G Ex ia IIC T4 Ga

Bayco Products, Inc.

640 S. Sanden Blvd., Wylie, TX 75098

Ex ia FLASHLIGHT FOR USE IN HAZARDOUS LOCATIONS

UL listed for use with Bayco Li-ion Battery Pack 5560-BATT

WARNING: Do not charge battery in a hazardous location

WARNING: Do not replace battery when an explosive

atmosphere is present

ID 4003544

Model XPR-5561 Permissible Cap Lamp Assembly

APPROVAL No. 19-A160003-1

TESTED FOR INTRINSIC SAFETY IN METHANE-AIR MIXTURES ONLY

WARNINGS:

1) Only to be charged on the surface, or underground in accordanc

e with the applicable

regulations pertaining to battery-charging stations (reference 30 CF

R 75.340) with a Bayco

Products, Inc. Model 5560-CHGR2

2) Do not open in areas where permissibility is required.

WARNINGS - INTRINSICALLY SAFE

yWarning: To prevent ignition of a hazardous atmosphere, the XPR-5561GC must only be

charged in an area known to be non-hazardous.

yWarning: Use only the approved Nightstick 5560-BATT Lithium-ion rechargeable battery

pack.

yWarning: To prevent ignition of a hazardous atmosphere, do not open the battery

compartment or attempt to exchange the battery pack while in the hazardous environment.

This task must ONLY be performed in an area known to be non-hazardous.

yWarning: Open the battery compartment on the XPR-5561GC and replace the approved

Nightstick 5560-BATT Lithium-ion rechargeable battery pack in fresh air only. To maintain

IP rating, torque battery compartment screws to 3.5 in-lb.

yWarning: replacement of the Lithium-ion rechargeable battery pack must be performed

by a quallied technician only.

yWarning: Substitution of components may impair intrinsic safety.

SPECIAL INSTRUCTIONS FOR INTRINSIC SAFETY

For personal safety, always conrm the rating of any known hazardous or potentially

hazardous location where the XPR-5561GC is to be used.

CAUTION

yRechargeable Lithium-ion batteries must be used and charged properly. Improper use

can result in serious injury, re, or death.

yDo not leave the battery in direct sunlight or use or store the battery inside cars in hot

weather.

yDo not expose the battery to water or salt water, or allow the battery to get wet.

yDo not store the battery with metallic objects that may cause a short circuit.

yImmediately discontinue use of the battery if the battery emits an unusual smell, feels hot,

changes color, changes shape or appears abnormal in any way.

yKeep out of the reach of children.

CHARGING THE LIGHT

CHARGER INPUT: 12 VDC Max

WARNING: Use only the supplied 5560-CHGR2 Charger & approved Nightstick

Lithium-ion Rechargeable Battery Pack.

yThe time required to charge the 5561 is conditional on the remaining charge left in the

Lithium-ion Rechargeable Battery Pack at the time of charging. The maximum charge time

required is approximately 6 hours.

yFully charge the 5561 before the rst use, or if the 5561 has been unused for several

months.

yWhen the 5561 is properly seated in the charger, the LED Charge Indicator light will

turn solid RED indicating that the Lithium-ion Rechargeable Battery Pack is charging. The

Lithium-ion Rechargeable Battery Pack is fully charged when the LED Charge Indicator

light turns GREEN.

yThe Lithium-ion Rechargeable Battery Pack does not have any Recharge Memory

Effect; therefore placing the 5561 in the charger prior to full depletion of the battery does

not adversely affect the battery life. The 5561 can be kept in the charger indenitely without

any negative impact on the battery or the battery life.

OPERATION

The XPR-5561GC is controlled by 2 Switches and has 6 separate lighting modes:

yHigh-brightness Spotlight

yLow-brightness Spotlight

ySpotlight Beacon

yHigh-brightness Floodlight

ySurvival-mode Floodlight

yDual-Light (both the Spotlight and Floodlight on at the same time)

Spotlight Modes

To activate the spotlight, press and release the spotlight switch. The default mode will

be low-brightness. Press the spotlight switch a second time to activate the high-brightness

mode. To activate the spotlight beacon press and hold the spotlight button until the beacon

turns on. Press the spotlight switch a third time to turn the light off.

Floodlight Modes

To activate the oodlight, press and release the oodlight switch. The default mode will

be high-brightness. To select the survival mode, press the oodlight switch a second time.

Press the oodlight switch a third time to turn the light off.

Dual-Light Mode

Dual-Light mode allows the user to turn on both the spotlight and the oodlight at the

same time. Dual-Light mode can be activated by simply pressing the spotlight switch and

then the oodlight switch. If the 5561 already has the spotlight or the oodlight on (regardless

of what brightness mode that light is in), pressing the switch for the light that is NOT on,

will activate Dual-Light mode. The user can leave Dual-Light mode and go back to either

spotlight or oodlight mode simply by pressing the switch for the mode that they wish to turn

off. To turn both lights off, simply press each of the switches independently.

Low Battery Warning

The XPR-5561GC has a Low Battery Warning feature. Once the battery charge falls below

2.9V, the Spotlight LED will blink once every minute while the light is on regardless of which of

the 5 modes the 5561 is in at the time. The Spotlight LED will continue to ash until the battery

is fully depleted or until the 5561 is recharged to have a remaining charge capacity greater

than 2.9V. This warning feature is an indication that the 5561 should be charged as soon as is

possible. If the 5561 is off, no such warning will take place.

THE XPR-5561GC FITS ON ANY HARD HAT THAT HAS A HARD HAT LAMP BRACKET

ATTACHED:

Nightstick NS-HMC9 Headlamp Bracket Mounting Instructions

yEnsure mounting surface is clean and oil-free (use alcohol wipe if needed)

yPrior to installing, determine mounting location that allows headlamp to fully tilt without

interfering with helmet brim.

yRemove adhesive backing.

yFirmly press bracket into place up for 30 seconds with at side facing up (see image).

yWhile supporting mount, slide headlamp clip into bracket slot. (Note: adhesive reaches

peak strength in 24 hours)

to attach to the HARD HAT lamp bracket

Slide the clip on the back of the XPR-5561GC into the slot on the top edge of the Hard

Hat Lamp Bracket and press down rmly until the clip is fully engaged into the bracket.

to remove from the Hard hat lamp bracket

Grasp the XPR-5561GC and pull up until the clip slides out of the Hard Hat Lamp

Bracket.

WARRANTY

LIMITED LIFETIME WARRANTY

Bayco Products, Inc. warrants this product to be free from defects in workmanship and

materials for the original purchaser’s lifetime. The Limited Lifetime Warranty includes the

LEDs, housing and lenses. Rechargeable batteries, chargers, switches, electronics and

included accessories are warranted for a period of two years with proof of purchase. Normal

wear and failures which are caused by accidents, misuse, abuse, faulty installation and

lightning damage are excluded.

We will repair or replace this product should we determine it to be defective. This is the

only warranty, expressed or implied, including any warranty of merchantability or tness for

a particular purpose.

For a complete copy of the warranty, go to www.baycoproducts.com/bayco-product-

support/warranties. Retain your receipt for proof of purchase.
